Section 10 Parts List
37
+ Available Separately
Models 750, 751, 754, 774, 791, 794 Parts List
Models 750, 751, 754, 774, 794
(HP62 Refrigerant: 750 -- J6110454, 751 -- J6080596, 754 -- J6080465, 774 -- J6092382, and 794 -- J4094101/up)
DESCRIPTION
PART
NUMBER
750
QTY.
751
QTY.
754
QTY.
774
QTY.
794
QTY.
W ARR.
CLASS
REMARKS PARTS
UPDATE
ADAPTOR A.-CASTER X18915 4 4 4 4 103
BEARING-FRONT 050216 1 1 2 2 2 000
BEARING-REAR SHELL 031324 1 1 2 2 2 000
+GUIDE-DRIP SEAL 028992 1 1 2 2 2 000
+NUT-BRASS BEARING 028991 1 1 2 2 2 000
+WASHER-BEARING LOCK 012864 1 1 2 2 2 000
BEATER ASSEMBLY X31761 1 1 2 2 2 103
+BLADE-SCRAPER 035174 2 2 4 4 4 000
BELT-AX40 023875 2 000
BELT-AX35 022848 2 4 000
BELT-AX34 025729 4 000
BELT-AX31 041575 4 000
BLOCK-TERMINAL-2 P 039422 1 1 2 2 2 103 SINGLE PHASE
BLOCK-TERMINAL-3 P 039423 1 1 2 2 2 103 THREE PHASE
SCREW-TERMINAL BLOCK 039420 2 2 4 4 4 000
BLOWER ASSEMBLY X53725-27 1 103
751-J9036440/UP-3PH
J9053627/UP-1PH
144
MOTOR-BLOWER 053481-27 1 103
BLOWER ASSEMBLY X53478-27 1 1 1 1 103
751-PRIOR TO J9036440-3PH,
J9053627-1PH
144
BOOT-CAPACITOR 031314 1 1 1 1 000
CAPACITOR-RUN 033047 1 1 1 1 103
CLIP-SCREEN BLOWER 053730 4 4 4 4 103
HOUSING-BLOWER 053727 1 1 1 1 103
MOTOR-BLOWER 053480-27 1 1 1 1 103
SCREEN-BLOWER 053729 1 1 1 1 103
WHEEL-BLOWER 053726 1 1 1 1 103
BOARD-LOG IC X36641SER1 1 1 2 2 2 212
BOARD-POWER X32326-SER 1 1 2 2 2 212
FUSE-SLO BLO 051272 1 1 2 2 2 103
BRUSH-BLACK (1” X 2”) 013071 1 1 1 1 1 000
BRUSH-DOUBLE END 013072 1 1 1 1 1 000
