+ Available Separately
48
Parts List
Models 750, 751, 754, 774, 791, 794
120613
Model 791
DESCRIPTION PART
NUMBER
791
QTY.
W ARR.
CLASS
REMARKS
079127RW00 -- 208--230V 60HZ 1PH, 079133RW00 -- 208--230V 60HZ 3PH -- 3 WIRE, W/C--BRISTOL (R404A), ROHS COMPLIANT -- STD
ARM--DRAW SWITCH--LEFT 069166 1 103 ARM--DRAW SWITCH--RIGHT 069167 1 103 BEARING--FRONT 050216 2 000 BEARING--REAR SHELL 031324 2 000
+GUIDE--DRIP SEAL 028992 2 000 +NUT--BRASS BEARING 028991 2 000 +WASHER--BEARING LOCK 012864 2 000
BEATER ASSEMBLY X31761 2 103
+BLADE--SCRAPER 035174 12 000
BELT--AX31 041575 4 000 BLOCK--TERMINAL 2P .25 SPADE 069015 1 103 BLOWER --100 CFM 012796--27 1 103
+GUARD--BLOWER 022505 1 103
BOARD--LOGIC--GEN 2.10--W/SEL DI X36641SER2 2 212 BOARD--POWER X32326--SER 2 212 BRUSH--BLACK (1” X 2”) 013071 1 000 BRUSH--DOUBLE END 013072 1 000 BRUSH--WHITE (1” X 2”) 013073 1 000 BRUSH--WHITE (3” X 7”) 023316 1 000 CABLE--RIBBON 032445 2 103 CAP--DESIGN 014218 3 000 CASTER--4” SWV 5/8” STEM 018794 2 103 CASTER--4” SWV 5/8” STEM W/BRAKE 034081 2 103 CHANNEL--REAR BEARING DRIP *794 041819 1 103 COMPRESSOR L64A113BBCA--40 048259--27H 1 512 208--230V 60HZ 1PH CAPACITOR--ST AR T 189--227UF/33 033044--1 1 103 CAPACITOR--RUN 25UF/440V 037431 1 103 RELAY--START--COMPRESSOR 062363 1 103 COMPRESSOR L63A113DBLA--40W CCH 048259--33H 1 512 208--230V 60HZ 3PH -- 3 WIRE COMPRESSOR--AUXILIARY 047701--27 1 512
