0RGHOV
3DUWV
%R[ $&DS 5HOD\ 0RGHO ;
,7(0 '(6&5,37,21 3$57 12
1 RELAY-START COMPRESSOR 051957-27
2 SCREW-10 X 3/8 TYPE B-HEX W. 015582
3 CONNECTOR-BX 3/8 STR 014569
4 CONNECTOR-BX 3/8 90 DEG 001793
5 BOX-CAPACITOR RELAY 030183
,7(0 '(6&5,37,21 3$57 12
6 CAPACITOR-RUN-20UF/440V 012906
7 CAPACITOR-START-189-227UF 033044-1
8 STRAP-CAPACITOR 7-11/32 037890
* COVER-CAP RELAY BOX 030315
* LABEL-WIRING SINGLE PHASE 036880-2
*NOT SHOWN
