Taylor 772 - Page 46


3DUWV
0RGHOV 
%R[ $&DS  5HOD\ 0RGHO   ; 
,7(0 '(6&5,37,21 3$57 12
 CAPACITOR RELAY A. 048130-27
1a RELAY-START-COMPRESSOR 036047
1b CAPACITOR-START-135-155UF/
330V
036048
,7(0 '(6&5,37,21 3$57 12
1c CAPACITOR-RUN-35UF/440V 048132
1d STRAP-CAPACITOR 7 IN 048059
1e SCREW-10 X 3/8 TYPE B-HEX 015582
2 CONNECTOR-BX 3/8 90D 001793
