Model 336 Specifications
Freezing Cylinder
Two, 2.8 quart (2.7 liter) volume.
Mix Hopper
Two, 8 quart (7.6 liter) capacity.
Beater Motor
Two, 1.0 hp.
Refrigeration Unit
One, approximately 9,500 btu/hr compressor.
Refrigerant R404A.
One independent (SHR) compressor, approximately
400 btu/hr. Refrigerant R134a.
(BTU's may vary based on compressor used.)
Electrical
One dedicated connection.
Maximum Minimum
Electrical
Fuse Size
Circuit Ampacity
208-230/60/1 Air 35 29
208-230/60/1 Water 35 26
208-230/60/3 Air 25 21
208-230/60/3 Water 25 18
This unit is manufactured in other electrical characteristics.
Refer to the Distributor Data Book for availability. (For exact
electrical information, always refer to the data label of the
unit.)
Air Cooled
Clearance: 3" (7.6 cm.) around all sides. A deflector has
been added to underside, preventing recirculation of warm
air. This will assure proper air flow across condensers to
obtain optimum performance.
Water Cooled
Water inlet and drain connections under side of base 3/8"
FPT
Dimensions
Width: 20-7/16" (51.9cm.)
Depth: 33-3/16" (84.3cm.)
Height: 60" (152.4 cm.)
Floor Clearance: 7-3/4" (19.7 cm.) mounted on
standard casters.
Approximate Weights
Net: 575 Ibs. (260.8 kgs.) Crated: 628 Ibs. (284.9 kgs.),
39.1 cu.ft. (1.10cu.m.)
Availability and specifications are subject to change
without notice.
This unit is designed and constructed to meet stringent safety
and sanitation requirements for NSF and UL.
