Page #14 background imageLoading...
Page #14 background image
4-2
OPERATOR PARTS IDENTIFICATION
Models C709 & C717
Operator Parts Identification
4
Model C709 Exploded View Parts Identification
Item Description Part No.
1 Panel-Side-Left 056963-SP1
2 Pan-Drip 11-5/8 Long 027503
3 Pin-Retaining-Hopper CVR 043934
4 Kit A.-Cover-Hopper X65368
5 Blade A.-Agitator X56591
6 Orifice 022465-100
7 O-ring-.643 OD x .077W 018572
8 Tube A.-Feed-SS-5/32 Hole X29429-2
9 Panel-Rear 083017-SP1
Item Description Part No.
10 Screw-1/4-20x3/8 RHM-SS 011694
11 Panel-Side-Right 058932
12 Panel A.-Front-Upper X59423
13 Panel A.-Front-Lower X81480
14 Shelf-Tray-Drip 056076
15 Stud-Nose Cone 055987
16 Tray-Drip 056858
17 Shield-Splash 049203
