OPERATOR PARTS IDENTIFICATION
Models C709 & C717
Operator Parts Identification
4
Model C717 Exploded View Parts Identification
Item Description Part No.
1 Kit A.-Cover-Hopper X67061
2 Orifice 022465-100
3 O-ring-.643 OD x .077 Wide 018572
4 Tube A.-Feed-SS-5/32 Hole X29429-2
5 Panel-Rear 059917
6 Panel-Side-Right 062161
7 Pan-Drip 12-1/2 Long 059736
8 Screw-1/4-20 x 3/8 RHM-SS 011694
9 Panel A.-Front(Upper) X59836
10 Stud-Nose Cone 055987
11 Panel A.-Front(Middle) X63879
12 Caster-4" SWV 3/4-10 STM 044106
Item Description Part No.
13 Panel-Corner-Frnt-Right 063087
14 Caster-4" SWV 3/4-10 Stem
w/Brake
046437
15 Panel A.-Front Lower X59854-SER
16 Shield-Splash-Wire-19-3/4 033813
17 Tray-Drip-19-5/8 L x 4-7/8 033812
18 Pan-Drip 19-1/2 Long 035034
19 Panel-Corner-Frnt-Left 063088
20 Pin-Retaining-Hopper CVR 043934
21 Blade A.-Agitator X56591
22 Panel-Side-Left 062160
To Next Page
