Taylor C803 User Manual

44
Parts List C801/C801R/F802/P802/C803/C803R/C804
DESCRIPTION REMARKSWARR.
CLASS
C804
QTY.
C803R
QTY.
C803
QTY.
C802C801R
QTY.
C801
QTY.
PART
NUMBER
DESCRIPTION REMARKSWARR.
CLASS
C804
QTY.
C803R
QTY.
C803
QTY.
P802
QTY.
F802 QTY.
C801R
QTY.
C801
QTY.
PART
NUMBER
DIAGRAM-WIRING *C801R* 072260-23 1 000 208V 60HZ 3PH DIAGRAM-WIRING *C803* 072159-23 1 1 000 208V 60HZ 3PH DIAGRAM-WIRING *F802* STD 072333-23 1 000 208V 60HZ 3PH DIAGRAM-WIRING *P802* V1-1-1 071860-23 1 000 208V 60HZ 3PH DIAGRAM-WIRING *C804* 073137-23 1 000 208V 60HZ 3PH DIVIDER A.-*C801* 2 LANE 070847 1 1 1 1 1 1 2 103 DIVIDER A.-*C801* COOK 070851 1 1 1 1 1 1 103 DIVIDER A.-3 LANE *C801* STAGE 070848 1 1 1 1 103 FUSE-2A 32VDC MINI-BLADE 071664 6 6 6 3 6 6 6 000 FUSE-3A 32VDC MINI-BLADE 071665 2 2 2 1 2 2 2 000 GASKET-CONTROL *C801* 070747 2 2 000 GASKET-CONTROL *C801* 070748 2 2 000 GASKET-PLATEN COVER *C801* UPP 070943 3 3 2 3 3 2 000 GUIDE-TROUBLESHOOT-WENDY'S 064274 1 1 1 1 000 HANDLE-ADJUST-PLATEN*C801* 070647 1 1 2 1 1 2 103 HANDLE-LIFT-PLATEN *C801* 072711 3 3 2 3 3 2 103 S/N K8124744 & UP - MUST
USE WITH X73187 ARM
HANDLE-LIFT-PLATEN *C801* 071324 * * * * 103 S/N K8124743 & PRIOR-MUST
USE WITH X70670 ARM ASSY- SEE S/B 0162SG
HARNESS-12VDC *C801* 070867 1 1 103 HARNESS-12VDC *C803* 072081 1 1 103 HARNESS-12VDC *F802 071842 1 1 103 HARNESS-12 VDC *P802* 071863 1 103 HARNESS A.-PLATEN-CLU *C801* 071631 1 1 1 1 103 HARNESS A.-PLATEN-CRU *C801* 071632 1 1 1 103 HARNESS A.-PLATEN-CMU *C801* 071633 1 103 HARNESS A.-PLATEN-CMU *C801R 072250 1 103 HARNESS A.-PLATEN CRU *C803* 072201 1 1 103 HARNESS A.-PLATEN CMU *C803* 072202 1 1 1 103 HARNESS-CAN BUS *C801* 071364 1 1 103 HARNESS-CAN BUS *C801R* 072251 1 1 103 HARNESS-CAN BUS *F802* 072683 1 103 HARNESS-CAN BUS *P802* 072688 1 103 HARNESS-CAN BUS *C804* 073134 1 103
