117
McDonald's Intelligap Grills
Parts
Control A.-Box - X72514-12 (C832 - 60 Hz) Parts Identification
ITEM DESCRIPTION PART NO.
1 CONTROL-MOTOR X72436-SER
2 SCREW-6-32X5/8 UNSLTD 041363
3 PANEL-PCB MOUNTING-L 072524
4 SCREW-10-32X3/8 SLTD HEX 044617
5 HARNESS A.-RELAY/PCB 072525
6 BRACKET-RELAY-HARNESS 074237
7 RELAY A.-5 HEATER LEFT X74211
8 SCREW-10-32X1/2 SERRATED 020982
9 RELAY-3P-40A 110/120 COIL 050841-12
10 SCREW-8X1/2 SLTD HEX 075763
11 CONNECTOR-BX 1/2 45 DEG 020511
12 BLOCK-TERMINAL 7P GREEN 024156
13 RELAY-3P-50A 110/120 COIL 051890-12
14 RELAY A.-5 HEATER RIGHT X74212
15 BUSHING-SNAP 15/16 ID 023396
16 NUT-1/4-20 WHIZ FLANGE LOC 017523
17 PANEL-PCB MOUNTING-R 072523
ITEM DESCRIPTION PART NO.
18 FILTER-CORCOM 2VR1 032567
19 BUSHING-SNAP 1-5/8ID X 2 OD 043637
20 BLOCK-TERMINAL 4P 1,2,L1,N 051647
21 SCREW-8X1 1/4 PHLP HD RD 039420
22 HOLDER-FUSE-15 A, 250 V 076299
23 BRACKET-FUSE 079867
24 BLOCK-TERMINAL 2P .25 SPD 051644
25 TRANS.-100VA 120/208/240 PRI 079800
26 LUG-GROUNDING 4-14 GA 017667
27 SCREW-1/4-20X5/8 SERRATED 017522
28 HARNESS-PCB/LOGIC 072527
29 HARNESS-PCB/GR SWITCH 072529
30 LABEL-COPPER COND ONLY 025948
31 LABEL-WIRING *CONTR 079538-12
* HARNESS A.-CNTL BOX X74157
* HARNESS A.-COMP/TB X79503
* FUSE-7A MDL 7-R 079837-070
*NOT SHOWN
