McDonald's Intelligap Grills
C835 Domestic Grill
The following table indicates the typical amp draw for the Model C835 (208/60/3):
Note: It is not possible to connect the heaters as a balanced 3phase load on this model. For simplification, the
heater loads are calculated using the highest load from one phase for ALL phases.
C835 Grill Cord 1 Cord 2
Left Side of Grill L1L2 L2L3 L1L3 L1L2 L2L3 L1L3
Lower Front Plate
5.29
Lower Middle Plate
Lower Rear Plate
Top Back Platen
4.97 4.97
Top Front Platen
4.97
Totals
Right Side of Grill L1L2 L2L3 L1L3 L1L2 L2L3 L1L3
Lower Front Plate
5.29
Lower Middle Plate
Lower Rear Plate
Top Back Platen
4.97 4.97
Top Front Platen
4.97
Totals
Combined Totals 13.9 13.9 13.9 13.9 13.9 13.9
C835 International Grill
The following table indicates the typical amp draw for the Model C835 (230400/50/3):
Note: It is not possible to connect the heaters as a balanced 3phase load on this model. For simplification, the
heater loads are calculated using the highest load from one phase for ALL phases.
C835 Grill Cord 1 Cord 2
Left Side of Grill L1N L2N L3N L1N L2N L3N
Lower Front Plate
4.78
Lower Middle Plate
Lower Rear Plate
Top Back Platen
8.99
Top Front Platen
4.99
Totals
Right Side of Grill L1N L2N L3N L1N L2N L3N
Lower Front Plate
4.78
Lower Middle Plate
Lower Rear Plate
Top Back Platen
8.99
Top Front Platen
4.99
Totals
Combined Totals 9.8 14.0 13.8
