C801/C801R/F802/P802/C803/C803R/C804 Operator Parts Identification
Section 4 Operator Parts Identification
C801
Figure 1
ITEM DESCRIPTION PART NO.
1 HANDLE-ADJUST-PLATEN 070647
2 PLATEN A.-ADJUSTABLE X71825-23
3 HANDLE-LIFT-PLATEN 072711
4 PLATEN A.-4OZ X71824-23
5 PLATEN A.-2OZ X71823-23
ITEM DESCRIPTION PART NO.
6 PANEL A.-SPLASH SHLD W/SP X70783
7 DIVIDER A.-2 LANE 070847
8 DIVIDER A.-3 LANE *STAGE 070848
9 SHIELD-BACKSPLASH 070765
10 DIVIDER A.-COOK 070851
