19
C801/C801R/F802/P802/C803/C803R/C804 Important: To the Operator
P802 Pick Up Window Unit
Figure 13
ITEM DESCRIPTION PART NO.
1 NODE A.-COMPLETE P802
STAGE/COOK
X71593-SER
2 CONTROL C801 MODE I/O 071242-SER
ITEM DESCRIPTION PART NO.
3 LIGHT-RED-230V 070880-27
4 CONTROL-RESET SWITCH
10A/250
070717
