52
Parts
Model SB25
150324
Model SB25 Internal Service Parts Identification
ITEM DESCRIPTION PART NO.
1 HARNESS-POWER UNIT-IO 081897
2 COUPLING-3/8 BARB-VALVED 081886
3 COUPLING-BULKHD-1/4-VALV 081191
4 PLUG A.-USB CABLE 073808
5 CABLE-USB-B FEM TO A MAL 081142
6 COVER A.-USB WATERPROOF 068583
7 SCREW-8-32X3/8 PPHD-SS 081167
8 COVER-PCB 081902
9 SCREW-10-32X5/8 PPHD 180-8 082354
10 KIT A.-BOARD-CIRCUIT X6519414SV
11 PCB A.-DISPENSE-I O X81132-SER
11a FUSE-.500A 250V 5X20 MM 083490
12 NUT-5/16-24 FINISHED HEX 029639-BLK
13 FOOT-FRONT-UNIT-IO 081113
14 FOOT-REAR-UNIT-IO 081112
ITEM DESCRIPTION PART NO.
15 KIT A.-MOTOR BLENDER X6519415SV
15a SCREW-6-32 X 1/2 HEX HEAD 065194-50
16 PUMP A.-CANE **SEE PAGE 57 X82356-12
17 SCREW-8-32X5/8 PPH 18-8 S.S 081890
18 WASHER-#8IDX1/2"ODX0.055 081893
19 SWITCH-A.ROCKER-SPST 083331
20 ROD-SUPPORT-ISLAND OASIS 065194-27
21 SCREW-10-32X1/2 PHL PAN 081168
22 WASHER-#10 INT TOOTH LOC 024420
23 KIT A.-BOARD-CIRCUIT DRIVE
(SEE PAGE 30)
X6519414SV
24 ROD-SUPPORT-KEYED-IO 065194-29
25 MANIFOLD A.-WATER
(SEE PAGE 56)
082222-12
26 PANEL-REAR-ISLAND OASIS 081120
27 O-RING 7/16 OD X .070 WALL 008403
