Taylor SB25 User Manual

Parts List
+ Available Separately, NNN = Not a Service Item, * See Remarks
60
Parts List Model SB25
150326
SB2512-W00 STANDARD & SB25 ROHS COMPLIANT
DESCRIPTION TAYLOR
PART NO.
SB25
QTY.
WARR. CLASS
REMARKS
ACTUATOR-RINSE-IO 081221 2 103 RINSE STATION
+ROD-PIVOT-ACTUATOR *SB20* 081220 1 103 RINSE STATION
BASE-STATION-RINSE-PARTIAL-IO 081175 1 103 BASE-ISLAND OASIS * 103 SEE KIT A.-BASE ISLAND OASIS BEZEL-KEYPAD *SB25* 081109-1 1 000 KIT-BLADE-CARTDRIGE 069087 1 000 BOARD-CIRCUIT *C019* DRIVE * SEE - KIT A.-BOARD-CIRCUIT*C029*DRIV BOTTLE-WASH-PLASTIC 044818 1 000 REPLACES X45080 S/N M4106299 BRUSH 1 000 SEE - KIT A.-BRUSH CABLE-COMMUNICATION-IO 081900 1 103 CABLE-KEYPAD-ISLAND OASIS 081110 1 103
+FILTER-FERRITE-FLAT CABLE-BB 084016 1 000
CABLE-USB-B FEM TO A MAL 081142 1 103 CHUTE-SHAVER-*SB25* 081121 1 000 U/D 241 CHG FROM 103 TO 000 CLAMP-CABLE-FLAT RIBBON 046367 1 000 ON RIBBON CABEL CLAMP-HOSE/CABLE *SB20* 081195 3 000 CLAMP-HOSE-MUBEA-15MM 083290 6 000 CLAMP-TUBE-DISPENSE-IO 082067 1 000 CLIP-PLASTIC 017609 1 000 USB CABLE CLIP-SIDE PANEL-ISLAND OASIS 081114 4 000 CONE-PLASTIC*C029*ISLAND OASIS 065194-48 1 103 COUPLING-BULKHD-1/4-VALVED-QD 081191 2 103 COUPLING-1/4ODX1/4OD JOHN GST 058302 2 103 COUPLING-3/8 BARB-VALVED 081886 1 103
+O-RING-7/16 OD X .070 WALL 008403 1 000
COVER A.-BOTTOM *SB20* X82223 1 103 COVER A.-HOPPER-IO 081239 1 000 COVER A.-USB WATERPROOF 068583 2 103 COVER-CONE*C029*ISLAND OASIS 065194-49 1 103 COVER-FILTER *SB20* 081181 1 000 COVER-PCB 081902 1 103 COVER-POWER-*SB20* 081180 1 103
