Taylor SB25 User Manual

65
+ Available Separately, NNN = Not a Service Item, * See Remarks
Model SB25 Parts List
DESCRIPTION REMARKSWARR.
CLASS
SB25
QTY.
TAYLOR
PART NO.
SCREW-6-32 X 1/2 TRUSS HEAD 065194-51 4 000 SCREW-SENSOR-CLIP-ICE-BIN 065194-55 1 000 SCREW-10-32X1/2 PHL PAN-SS 081168 7 000 SCREW-10-32X5/8 PPHD 180-8 S.S 082354 2 000 SCREW-6-32X1/2 PHL PAN-SS-SEMS 081166 2 000 SCREW-6X3/8-HWH-TYPE B 081111 9 000 SCREW-8-32X1/4 PHIL.PAN HD 068121 4 000 SCREW-8-32X3/8 PPHD-SS-NYLOK 081167 5 000 SCREW-8-32X5/8 PPH 18-8 S.S 081890 4 000 KIT A.-SEAL SHAFT MOTOR *C029* X6519418SV 1 000 SEAL-Y FILTER *SB20* 081183 1 000 SENSOR-ICE-BIN 065194-53 - 103 USE X80552 KIT A.-ICE BIN SENSOR SHIELD-WATER-PCB *SB25* 082467 1 000 SPACER-PCB MOUNT-IO *SB25* 081898 2 000 SUPPLY-POWER-IO 081217 1 103 RINSE STATION SUPPORT-MOTOR-SHAVER-FOAM-IO 081170 * 000 REMOVED AS OF S/N M5033649 SUPPORT-PCB-DISPENSE-IO 082332 8 000 SWITCH-REED 13-15AT *SB25* 083780 2 103 S/N M5011117 & UP-REPLACES 081190 RINSE STATION SWITCH-A.RCKR-SPST ON/NONE/OFF 083331 1 103 ADDED S/N M4072429 TUBE-.170ID X .250OD R403021 4' 000 TUBE-.250ID X .375OD R403025 10' 000 DISPENSE WATER SYSTEM
+INSERT-NUT-COMPRESSION-.375 083295 1 000 CONNECT DISP UNIT TO WATER SORCE +NUT-COMPRESSION-.375-WATTS 081246 1 000 CONNECT DISP UNIT TO WATER SORCE +INSERT-COUPLING 081216 1 000 CONNECT DISP UNIT TO WATER SORCE
TUBE-.250ID X .375OD R403025 10' 000 RINSE STATION TO WATER SOURCE
+INSERT-NUT-COMPRESSION-.375 083295 1 000 RINSE STATION TO WATER SOURCE
TUBE-DISPENSE-CANE-IO 082168 1 103 TUBE-DISPENSE-WATER-IO 082167 1 103 TUBE-DRAIN-INTERNAL 065194-52 1 000 TUBE-VINYL 1/4 ID X 3/8 OD R30312 .5' 000 VALVE-SOLENOID 082222-123 2 103 WASHER-#10 INTERNAL TOOTH LOCK 024420 6 000 WASHER-#8IDX1/2"ODX0.055 081893 4 000
