3.2.1 Wiring area view
3.2 Wiring area description
No. Description
Ground terminal
Description
Kinergy (data logging stick)
installation position
Grand for PV cable
Main switch
1
3
2
Output circuit breaker
Input circuit breaker
Gland for BTS,VS etc.
communication cable
5
6
4
No.
7
9
8
11
12
10
Gland for battery -
Gland for AC output1
Gland for battery +
Gland for AC input
Gland for AC output2
1
2
3
6 7 8 9 10 11 12
5
4
