LMP1218-PWM Master Power Unit User Manual
IDM Technologie
8
[1]15
GND : Buzzer Footstep
8
Loads
[2]1
POS : Lighting Right side
[2]2
GND : Lighting Right side
[2]3
POS : Buzzer Footstep
[2]4
POS : Lighting Left side
[2]5
POS : Lighting Left side
[2]6
GND: In/Out Footstep (COM)
[2]7
POS : Power Tablet
[2]8
GND : Power Tablet
[2]9
Out Footstep (Normally Open)
[2]10
POS + Lifting bed
[2]11
GND - Lit électrique
[2]12
In Footstep (Normally Open)
[2]13
POS + Plug 12V Kitchen
[2]14
GND - Plug 12V Kitchen
[2]15
M1 - Footstep
[2]16
POS + Plug USB Kitchen/Bedroom
[2]17
GND - Plug USB Kitchen/Bedroom
[2]18
Footstep
9
Loads
[3]1
POS : Permanent Autoradio
[3]2
GND :
[3]3
POS : SAT antenna
[3]4
POS : Combi + TRUMA/ALDE control
[3]5
GND : Combi + TRUMA/ALDE control
[3]6
GND : Elec Fridge
[3]7
POS : TV
[3]8
GND : TV
[3]9
POS : Elec. Fridge
10
Signal terminal
[7]1
D+ (active high +BAT
[7]2
Switch ON/OFF (Main)
[7]3
D+ (active down GND)
[7]4
[7]5
Sidelights (active high +BAT)
[7]6
+APC (active high +BAT)
[7]7
Sidelights (active down GND)
[7]8
+APC (active down GND)
[7]9
Switch ON/OFF (NO)
[7]10
Footboard End of stroke (COM)
[7]11
Footboard End of stroke (NO)
[7]12
11
Grey water tank
[6]1
CW-REF
[6]2
CW-25%
[6]3
CW-50%
[6]4
CW-75%
