APPENDIX C
M5TROUBL
Rev 1.5 Page 7
APPENDIX D
TECHNICAL SPECIFICATIONS M5000
All Specs is measured with ADA-1 STEREO ANALOG IN/OUT module installed.
Max. Input Level
@ - 8 dB gain, + 22,0 dBu
@ 0 dB gain, + 14,8 dBu
@ 12 dB gain, + 2,8 dBu
Input Impedance
20 KOhm, electronically balanced, pin 2+, 3-
Input Gain
± 12 dB
Input CMRR
DC - 1 KHz, > 60 dB
1 KHz - 20 KHz, > 40 dB
Max. Output Level
+ 22 dBu
Output Signal Balance
>40 dB @ 1 KHz (BBC method)
Output Impedance
100 Ohm, electronically balanced, floating
type, pin 2+, 3-
Output Gain
-18 dB to + 12 dB
Frequency Response
10-22 KHz, +0 -1 dB, Fs=48.0KHz
10-20 KHz, +0 -1 dB, Fs=44.1KHz
10-15 KHz, +0 -0.5 dB, Fs=32.0KHz
Total Harmonic Dist.
< 0.03 %, 1 KHz, 0 dBu
Inter modulation Dist.
< 0.03 %
Dynamic Range
> 98 dB
Crosstalk
< -80 dB @ 1 KHz
Group Delay Linearity
< 5 µS
Phase Linearity
Better than 5º
Digital Conversion
Input: Delta Sigma 64x oversampling, 18 bit res.
Output: Linear 8x oversampling, 20 bit res.
Sampling Rate
48.0 KHz, 44.1 KHz, 32.0 KHz
Environment
Operating 0º to 50º, storage -20º to 60º
Power Requirements
100 - 240 Vac, 50-60 Hz
