MIDI & SMP
TE
M5MIDIIN
Rev 1.4 Page 11
MIDI System-Exclusive P
age:
SYSEX ID
SYSEX ID
SYSEX ID
SYSEX ID
#
#
#
#
ME
NU
MENU
MENU
MENU
0
0
0
0
MIDI
MIDI
MIDI
MIDI
Turn the
Device#
knob to set the device-number of this M5000.
The Device# is all y
ou’ll ever need to know about Sy
sex. This number must be set to same
value both on y
our Macintosh/PC-editor and on y
our M5000 in order for them to be able to
‘find’ each other.
171
173
Table of Contents
Default Chapter
2
Introduction
2
Hardware
3
Software
3
Why a Mainframe ?
3
Floppy Disk
4
Memory Card
5
Soft/Hardware Future Options
5
General Instructions
6
Front Panel
7
Concept
12
Program Handling
12
Program Parameters
13
Parameters: Create and Rename Program
14
Parameters: File Buffer Handling
14
Parameters: Recall and Storage of Programs
14
Compare a Program
15
A/A&D: Analog Input and both Analog and Digital Output
16
D/A&D: Digital Input and both Analog and Digital Output
16
Utility Handling
16
M5000 as a Multieffect Unit
17
Digital Input and Digital Output
18
Digital Storing Media for Instruments
18
Insert
18
M-Clock
19
G-Levels Menu
20
MIDI Menu
20
File Menu
21
Meters Menu
21
Pedal Menu
21
Configuration Menu
22
M5000 Option
22
Show Config
22
Smpte Menu
22
Rom Presets
23
The Basic Algorithms
23
Edit Parameters
24
Reverb
24
Pitch down
45
Pitch up
45
Pitch
49
Delay
56
Param.eq
79
Dynamic1
87
Digital Equalizer
98
Toolbox
98
Dithering
99
Fading
100
Meters
100
Stereo Adjust
100
The Fletcher-Munson Equal Loudness Contour Curves
101
Lowcut
102
Page 3, Level Meter
102
Page 4, Correlation Meter:
103
Configuration
108
Multiple Atac/M5000/M5000X Setup
109
Software Installation
110
General Handling
112
Hardware Installation
112
Mounting Modules
112
Removing Modules
112
Option Installation
114
Ref. Code
114
Serial Number
114
Check the Option Installed
115
Installing the Option
115
Simm Pack Installation
118
Start of Installation
118
Removing the Modules
118
INSTALLING SIMM Pack's on the DSP-MODULE
119
Selection of the Simm Pack Modules
119
Self Test Procedure in Bios 1.07
148
Errors Detected
149
JEIDA Test will Destroy All Data on Card
149
M5000 Diagnostics
149
Tests OK
149
Press DO and Verify that LCD Is Filled
150
SESSION 2: Front Panel Test
150
Turn a and Verify All Leds
150
Verify Backlight & Viewing Angle Knob
150
Troubleshooting/Err. Codes
151
Technical Specifications
152
Controls & Displays
155
Rear Panel Connections
156
Dsp-1 Connections
157
Ada-1 Connections
158
Cables for Digital Audio
159
Tc Bbs
160
Bios and Flash Minimum Requirement
161
Applications and MIDI
162
Introduction to MIDI Operation
162
MIDI INPUT Page
162
Setting up the M5000 for MIDI Operation
162
MIDI Utility-Page
164
Program Changes
164
Program Map Page
164
Reverb-1 & Reverb-2
165
Reverb-3
165
MIDI Controllers
165
Chorus-1
166
Delay-1
166
Nonlin-1
166
Delay-2
167
Revpitch
167
Ambience
168
Pitch-1
168
Pitch-2
168
Tapfac-1
169
System-Exclusives
171
MIDI System-Exclusive Page
172
Guided Tours
173
How Do I Update with a New Software ?
174
Software Update
174
How Do I Call up a Program
175
How Do I Edit and Store a Program ?
175
Disk/Card Handling
176
How Do I Format a Floppy Disk/Memory Card ?
176
How Do I Load Programs into the M5000 ?
176
How Do I Save My Programs to Disk/Card ?
176
Loading from a Memory Card
177
MIDI System-Exclusive Documentation
178
Table of Contents
179
Overview
181
The Parameter-Access Dump
181
System-Configuration/Info Dumps
181
Preset-Handling Dumps
181
1 Introduction
181
General Format
181
2 Individual Parameter-Access
183
Parameter-Ids and Values
183
Overview
183
Requesting Parameter Values
183
Setting Parameter Values
184
Truncation and Mutual Dependencies
184
Linked Parameters
184
The Parameter-Queue
184
Spontaneous Data-Emissions
185
Conversion Routines
185
Convertmiditopar
185
Convertpartomidi
185
Convertvaluetomidi
186
3 Algorithm-Parameters
187
Reverb-1 & Reverb-2
187
Reverb-3
187
Nonlin-1
188
Chorus-1
188
Delay-1
188
Delay-2
189
Revpitch
190
Pitch-1
190
Pitch-2
191
Tapfac-1
191
Ambience
193
Dynamic1
193
Meters
194
3.12.2 Meter Code-Example
195
Nothing -1
196
3.12.3 Mutual Dependencies
196
Toolbox
196
3.13.1 Special Considerations
198
4 System-Parameters
199
VU-Meters
199
Communication
199
Overview
199
Calculations
200
Hardware-Specific Parameter Ranges
200
5 Preset-Handling
201
Conversions and Ids
201
Overview
201
Preset-Numbers
201
Algorithm-Ids
201
Preset-Names
201
Preset Information
202
Recall Preset
202
6 C Programming-Interface
203
Programming-Interface
203
Using the Interface
203
