49
Analog Inputs
Connectors: 1/4" phone jack, unbalanced (Ring: grounded)
Impedance: 1 MOhm
Max. Input Level: +21 dBu
Sensitivity: @ 15 dB headroom: -26 dBu to +6 dBu
A to D Conversion: 24 bit (1 bit, 128 times oversampling)
A to D Delay: 0,9 ms @ 44.1 kHz
Dynamic Range: >105 dB
THD: 0.003% @ 1 kHz, 6 dB below full scale
Frequency Response: +0/-0.5 dB (20 Hz - 20 kHz)
Crosstalk: <-60 dB (20 Hz - 20 kHz)
Analog Outputs
Connectors: 1/4" phone jack, balanced
Impedance: 100 Ohm (active transformer)
Max. Output Level: +22 dBu
Full Scale Output Range: -10 dBu to +22 dBu
D to A Conversion: 24 bit (1 bit, 128 times oversampling)
D to A Delay: 0.6 ms @ 44.1 kHz
Dynamic Range: >100 dB
THD: 0.005% @ 1 kHz, 6 dB below full scale
Frequency Response: +0/-0.5 dB (20 Hz - 20 kHz)
Crosstalk: <-60 dB (20 Hz - 20 kHz)
Digital Inputs and Outputs
S/PDIF In/Out: Coaxial, RCA Type
Formats: EIAJ CP-340, IEC 958, S/PDIF (24 bit)
Sample Rate: 44.1 kHz
PCMCIA Interface
Connector: PCMCIA Type 1 cards
Standards: PCMCIA 2.0, JEIDA 4.0
Card Format: Supports up to 2 MB SRAM
Control Interface
MIDI: In/Out/Thru: 5 Pin DIN
External control: 1/4" phone jack
General
Finish: Anodized aluminum face. Plated and painted steel chassis
LED: 3 LED meters, 5 x 14 dot LED-matrix
LCD: 56 x 128 dot graphic LCD-display
Dimensions: 19" x 1.75" x 8.2" (483 x 44 x 208 mm)
Weight: 5.0 lb. (2.25 kg)
Mains Voltage: 100 to 240 VAC, 50 to 60 Hz (auto-select)
Power Consumption: <20 W
Backup Battery Life: >10 years
EMC
Complies with: EN 55103-1, EN 55103-2 and
Class B limits of FCC rules, part 15
Safety
Certified to: EN 60065, UL 1419
Environment
Operating Temperature: 32 °F to 122 °F (0 °C to 50 °C)
Storage Temperature: -22 °F to 167 °F (-30 °C to 70 °C)
Humidity: Max. 90% non-condensing
NOTE: Due to continuous development and standardization all specifications are subject to change without notice
TECHNICAL SPECIFICATIONS
