Technical specifications
Viscous Vibe English manual 2015-04-27 24
Please note that due to continuous development, the following specifications are subject to change without further notice.
Bypass mode True Bypass (Buffered Bypass optional)
Signal circuitry Analog dry-through
Dimensions (width x depth x height) 72 x 122 x 50mm – 2.8 x 4.8 x 2.0”
Input connector 2 Standard ¼” jacks – mono/TS with automatic mono/stereo sensing
Output connector 2 Standard ¼” jacks – mono/TS with automatic mono/stereo sensing
Power input Standard 9V DC, centre negative >100mA (power supply not included)
Battery option Standard 9V (battery not included)
Input impedance 1MΩ
Output impedance 100Ω
USB port Mini USB connector for uploading and editing custom TonePrints and for software updates

TC Electronic Viscous Vibe Specifications

General

Product type	Pedal
Product color	Green
Built-in display	No
Manual	Yes

Weight and Dimensions

Depth	122 mm
Width	72 mm
Height	50 mm
