KMS-2/Exia Transmitter
Installation and Operating Manual
ATEX
Rev D 20/09/2018 KMS-2/Exia IOM Page 5 of 13
TRANSMITTER
Fig 1
Typical Installation When Fitted to Magnetic Level Gauge
DISPLAY
TOP MOUNT OPTION
BOTTOM MOUNT OPTION
SCREW
CLAMP
GAUGE
CHAMBER
INSULATION
IF REQUIRED
TRANSMITTER
CLIP
