TC-Helicon VoiceLive User Manual

38
GLOBAL EDIT SCREENS
VoiceLive has EQ and dynamics processing optimized for vocals. This screen and the following
provide parameters for setting up the EQ and dynamics processing.
EDIT 1 knob: DYNAMIC PROCESSING ASSIGN
. This allows assigning of dynamic processing (com-
pressor and gate) to the lead voice, harmony voices, both lead and harmony voices
or neither. Hint: assigning only to the lead voice with a medium compressor setting
(threshold: -15dB, ratio:2:1) keeps the lead voice a consistent volume but keeps
harmony levels following the singers level. This gives control of harmony levels
with mic technique.
EDIT 2 knob: EQ A
SSIGN
. This allows assigning of the three band EQ to the lead voice
, harmony
voices, both lead and harmony voices or neither.
Compressor / Gate settings. The compressor in VoiceLive has auto makeup gain to a maximum of
+20dB. This means that the volume level of the signal will be increased for most volume levels of
input with the compressor enabled.
EDIT 1 knob: C
OMPRESSOR THRESHOLD LEVEL. Range: 0 to -60 dB.
EDIT 2 knob: COMPRESSION RATIO. Range: 1.1:1 to 64:1
EDIT 3 knob: G
ATE THRESHOLD. Range: Off, -70dB to 0dB
VoiceLive has an extremely flexible 3 band EQ with frequency adjustable high and low shelving
bands and a fully parametric band with Q, frequency and Gain controls. This screen gives control
over the high and low shelf EQ parameters.
EDIT 1 knob: LOW SHELF
FREQUENCY
(Hz). Range: 80Hz to 16kHz
EDIT 2 knob: LOW SHELF CUT/BOOST
(dB). Range: Cut (12 dB per octave low cut at the L
OW
SHELF FREQUENCY), -12dB to +12dB
EDIT 3 knob: H
IGH SHELF FREQUENCY (Hz). Range: 80Hz - 16kHz
EDIT 4 knob: H
IGH SHELF CUT/BOOST (dB). Range: Cut (12 dB per octave high cut at the HIGH
SHELF FREQUENCY), -12dB to +12dB.
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
LowShlf HighShlf
IO 6
L200+3 H4k0+7
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
Thrsh Ratio Gate
IO 5
-12 2.5 -45
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
DynAssgn EQAssgn
IO 4
Lead Lead+Hm

TC-Helicon VoiceLive Specifications

Analog Inputs

mic impedance	3.6/1.8 kOhm
line impedance	21/13 kOhm
line input level at 0 dBFS	24 dBu to 0 dBu

Analog Outputs

output impedance	40 Ohm
max output level balanced	20 dBu
max output level unbalanced	14 dBu

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Supplementary

dimensions	11.1" x 10.25" x 3.5" (282 x 260 x 89 mm)
weight	5.9 lb. (2.7 kg)
mains voltage	100 to 240 VAC, 50 to 60 Hz (auto-select)
