TC-Helicon VoiceLive User Manual

30
PRESET EDIT SCREENS
EDIT 1 knob: REVERB T
YPE
. Available reverb models include:
• Living
Room
• Chamber
• Club
• Classic Hall
• Concert
Hall
• Large Cathedral
•Vocal S
tudio
•Vocal Room
•V
ocal Hall
• Ambience
• Live Reverb
• Plate 1
• Plate 2
•Spring
Note: Changing the R
EVERB TYPE
will affect the other reverb parameters.
EDIT 1 knob: R
EVERB DECAY TIME.
EDIT 2 knob: REVERB
PRE-DELAY TIME
. Sets the delay time prior to the reverb output. Large rooms
typically have reverbs that start much later than the initial signal.
EDIT 1 knob: REVERB LOW COLOR. Sets the low frequency characteristics of the reverb.
EDIT 2 knob: R
EVERB HIGH COLOR. Sets the high frequency characteristics of the reverb .
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
LowColor HiColor
FX 5
Round Clear
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
DecayTime PreDly
FX 4
1.8s 16ms
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
Reverb Type
FX 3
Classic Hall

TC-Helicon VoiceLive Specifications

Analog Inputs

mic impedance	3.6/1.8 kOhm
line impedance	21/13 kOhm
line input level at 0 dBFS	24 dBu to 0 dBu

Analog Outputs

output impedance	40 Ohm
max output level balanced	20 dBu
max output level unbalanced	14 dBu

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Supplementary

dimensions	11.1" x 10.25" x 3.5" (282 x 260 x 89 mm)
weight	5.9 lb. (2.7 kg)
mains voltage	100 to 240 VAC, 50 to 60 Hz (auto-select)
