TC-Helicon VoiceTone Harmony-G User Manual

25
Specifications
Analog Inputs
 Mic Connector Balanced XLR, Input Impedance 1kOhm
 Mic Input Sensitivity @ 0dBFS -44dBu to +2dBu
 Mic Input Sensitivity @ 12dB headroom -56dBu to -10dBu
 Guitar In Connector Unbalanced 1/4”, Input Impedance 1MOhm
 Guitar In Sensitivity +15dBu @ 0dBFS
 EIN -126dBu @ max. mic amp gain, Rg = 150 Ohm
Analog Outputs
 Main Output Connectors Balanced XLR
 Output Impedance 40 Ohm
 Output Level +2dBu @ 0dBFS
 Guitar Thru Connector Unbalanced 1/4” Phone Jack
 Guitar Thru Output Impedance 270 Ohm
Input to Output Analog Audio Performance
 Dynamic Range, Mic. @ Min gain >108dB, 20 Hz - 20kHz *A-weighted
 Dynamic Range, Mic. @ -18dBu sensitivity > 104dB, 20hz - 20kHz*
 THD+ Noise, Mic. @ Min gain <-90dB
 Frequency Response, max gain -1.5dB @ 40 Hz, +0/-0.3 dB (200Hz to 20 kHz)
 Guitar In to Thru Dynamic Range >119dB
 Tuning Mute Attenuation >100dB
Conversion Characteristics
 Sample Rate 48 kHz, Converter AKM AK4620B
 AD / DA Conversion 24 bit, 128x oversampling
bitstream
EMC & Safety
 Complies with EN 55103-1 and EN 55103-2
FCC part 15, Class B, CISPR 22, Class B
 Certified to IEC 65, EN 60065, UL6500 and
CSA E60065 CSA FILE #LR108093
Environment
 Operating Temperature 32° F to 122° F (0° C
to 50° C)
 Storage Temperature -22° F to 167° F (-30° C
to 70° C)
 Humidity Max. 90 % non-condensing
Supplementary
 Dimensions 130mm x 132mm x 41mm (5" x
5.25" x 1.5")
 Weight 1.5 lb. (0.72 kg)
 Warranty Parts and labor 1 year
All specifications and features subject to change
without notice.

TC-Helicon VoiceTone Harmony-G Specifications

Analog Inputs

mic input impedance	1 kOhm
mic input sensitivity at 0dBFS	-44 dBu to +2 dBu
mic input sensitivity at 12dB headroom	-56 dBu to -10 dBu
guitar input impedance	1 MOhm
guitar input sensitivity	+15 dBu at 0dBFS
equivalent input noise	-126 dBu at max. mic amp gain, Rg = 150 Ohm

Analog Outputs

main output impedance	40 Ohm
main output level	+2 dBu at 0dBFS
guitar thru output impedance	270 Ohm

Input to Output Analog Audio Performance

dynamic range, mic at min gain	>108 dB, 20 Hz - 20 kHz A-weighted
dynamic range, mic at -18 dBu sensitivity	>104 dB, 20 Hz - 20 kHz
thd+ noise, mic at min gain	<-90 dB
frequency response at max gain	-1.5 dB at 40 Hz, +0/-0.3 dB (200 Hz to 20 kHz)
guitar in to thru dynamic range	>119 dB
tuning mute attenuation	>100 dB

Conversion Characteristics

sample rate	48 kHz
converter	AKM AK4620B
ad / da conversion	24 bit, 128x oversampling

Operating Environment

operating temperature	32 °F to 122 °F (0 °C to 50 °C)
storage temperature	-22 °F to 167 °F (-30 °C to 70 °C)
humidity	Max. 90 % non-condensing

Weight and Dimensions

dimensions	130 mm x 132 mm x 41 mm (5" x 5.25" x 1.5")
weight	1.5 lb (0.72 kg)
