About TC-Helicon
At TC-Helicon we truly believe that the voice is the
world's most beautiful instrument. We don't mean to
degrade other beautiful instruments, but the singing
voice is the anthropological source for all things melodic.
You should know there is a dedicated group of
engineers, researchers and product specialists based in
Victoria BC, Canada, who spend every waking moment
of their working lives listening, talking, singing, and
interacting with singers and those who have passion for
the singing voice.
All this knowledge and experience is used to design
products respecting and empowering the modern
vocalist. Our products focus on removing barriers and
inspiring creativity in performance. That's why our
products range from near-field personal vocal monitors
to floor-based vocal multi-effects pedals.
Enjoy!
The TC-Helicon Team
a TC Group company
Introduction

TC-Helicon VoiceTone Harmony-G Specifications

Analog Inputs

mic input impedance	1 kOhm
mic input sensitivity at 0dBFS	-44 dBu to +2 dBu
mic input sensitivity at 12dB headroom	-56 dBu to -10 dBu
guitar input impedance	1 MOhm
guitar input sensitivity	+15 dBu at 0dBFS
equivalent input noise	-126 dBu at max. mic amp gain, Rg = 150 Ohm

Analog Outputs

main output impedance	40 Ohm
main output level	+2 dBu at 0dBFS
guitar thru output impedance	270 Ohm

Input to Output Analog Audio Performance

dynamic range, mic at min gain	>108 dB, 20 Hz - 20 kHz A-weighted
dynamic range, mic at -18 dBu sensitivity	>104 dB, 20 Hz - 20 kHz
thd+ noise, mic at min gain	<-90 dB
frequency response at max gain	-1.5 dB at 40 Hz, +0/-0.3 dB (200 Hz to 20 kHz)
guitar in to thru dynamic range	>119 dB
tuning mute attenuation	>100 dB

Conversion Characteristics

sample rate	48 kHz
converter	AKM AK4620B
ad / da conversion	24 bit, 128x oversampling

Operating Environment

operating temperature	32 °F to 122 °F (0 °C to 50 °C)
storage temperature	-22 °F to 167 °F (-30 °C to 70 °C)
humidity	Max. 90 % non-condensing

Weight and Dimensions

dimensions	130 mm x 132 mm x 41 mm (5" x 5.25" x 1.5")
weight	1.5 lb (0.72 kg)
