11
Basic TV Operations
Looking for your favourite show? Use Search for quick
access to all your favourite on demand from ABC iview,
SBS On Demand, 7+, 9Now and 10 Play.
All in one place, all for free.
HbbTV
HbbTV (Hybrid broadcast broadband TV) is a service
o󰀨ered by certain broadcasters and available only on
some digital TV channels. HbbTV delivers interactive
television over broadband Internet. These interactive
features are added to and enrich the normal digital
programs, and include services such as digital teletext,
electronic program guide, games, voting, specic
information related to the current program, interactive
advertising, information magazines, catch-up TV, etc.
To use HbbTV, please ensure your TV is connected to
Internet and HbbTV is switched on.
Notes:
-
HbbTV services are broadcast- or country-
dependent and may be unavailable in your area.
-
You cannot download les to your TV with HbbTV
function.
-
Application provider or broadcasting related
conditions may cause an HbbTV application to be
unavailable momentarily.
-
To access HbbTV applications, you must connect
your TV to the Internet via a broadband link. HbbTV
applications may not work correctly in case of
network related issues.
HbbTV Access
1.
Press
on the remote control, select
(Settings)
>
System > HbbTV Settings > HbbTV
and press
OK
to enter.
2.
Press
OK
to activate it.
3.
When you tune to a digital TV channel that offers
HbbTV, this will be signaled to you by an on-screen
indication (generally a red button, but other colour
buttons may also be used). Press the indicated
colour button to open the interactive pages.
4.
Use
Up/Down/Left/Right
and the colour buttons to
navigate through the HbbTV pages and press
OK
to
confirm.
HbbTV Deactivation
To avoid disturbances that may be caused by HbbTV
broadcasting tests, you can turn o󰀨 the HbbTV function:
1.
Press
on the remote control, select
(Settings)
>
System > HbbTV Settings > HbbTV
and press
OK
to enter.
2. Press OK to deactivate it.
3.
Press
to return to the previous menu.
Enabling Subtitle Languages on Digital TV Channels
1.
Press
on the remote control, select
(Settings)
>
Channels & Inputs > Channels > Subtitle > Digital
Subtitle Language 1st
and press
OK/Right
to enter.
2.
Press
Up/Down
to select a subtitle language as
your preferred language and press
OK
to conrm.
3.
Press
Up/Down
to select
Digital Subtitle
Language 2nd
and press
OK
/Right
to enter.
4.
Press
Up/Down
to select a secondary subtitle
language and press
OK
to conrm.
5.
Press
to return to the previous menu.
Selecting a Subtitle Type on Digital TV Channels
1.
Press
on the remote control, select
(Settings)
> Channels & Inputs > Channels > Subtitle >
Subtitle Type
and press
OK/Right
to enter.
2.
Press
Up/Down
to select a subtitle type and press
OK to confirm. You can select Hearing Impaired
to display the hearing impaired subtitles with your
selected language.
3.
Press
to return to the previous menu.
Using EPG
(Electronic Program Guide)
EPG is an on-screen guide that displays scheduled
digital TV programmes. You can navigate, select and
view programs.
1.
Press
on the remote control, select
(Settings)
> Channels & Inputs > Channels > EPG
and press
OK to enter, or press
directly (if available) on
the remote control, the
Program Guide
menu will
appear, which allows you to get information about
the current or next program playing on each channel.
Navigate through the different programs using the
Up/Down/Left/Right
buttons on the remote control.
2.
Use the related buttons shown at the left of the
screen to view EPG.
- Filter:
Program guide lter for digital TV programs.
Navigate through the di󰀨erent types using the
Up/Down
buttons on the remote control.
Select one or more types, which you want to
highlight from the type list, press
OK
to select or
deselect. A checkmark will appear to the left of
the type when selected.
- Reminders:
Press the
OK
button to enter, then
select
Schedule Reminder
or
Schedule Record-
ing
to set Channel, Date, Reminder Time and so
on.
3.
Press
to return to the previous menu.
Freeview
Never miss a thing with freeview!
Find out what’s on now, next or over the next 7 days
with the easy to use TV guide.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 75C745 and is the answer not in the manual?

TCL 75C745 Specifications

General IconGeneral
DVI portNo
Headphone outputs1
RF connector typeF, IEC
RF ports quantity2
HDMI ports quantity4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial out0
Audio Return Channel (ARC)Yes
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
Video appsAmazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Smart modesSports
Operating system version11.0
App distribution platformGoogle Play
Operating system installedGoogle TV
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Audio decodersDTS, Dolby Atmos, Dolby Digital, DTS Virtual:X, DTS-HD, Dolby Digital AC4, Dolby TrueHD
RMS rated power30 W
Audio output channels2.0 channels
Equalizer bands quantity7
Pallet width1900 mm
Pallet net height1300 mm
Pallet net length800 mm
Pallet net weight178400 g
Quantity per truck168 pc(s)
Quantity per pallet4 pc(s)
Master (outer) case width1843 mm
Master (outer) case height1120 mm
Master (outer) case length187 mm
Master (outer) case weight39120 g
Number of layers per pallet1 pc(s)
Number of pallets per truck42 pc(s)
Master (outer) case GTIN (EAN/UPC)5901292519629
Maximum number of stacking cartons2 pc(s)
Wi-Fi standards802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.0
Browser supported-
Bluetooth profilesA2DP, HID
Stand typeCenter stand
Product colorBlack
Heavy metals freeCd (cadmium)
Panel mounting interface400 x 300 mm
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Analog signal format systemNTSC, PAL BG, PAL DK, PAL I, PAL L, SECAM B/G, SECAM D/K, SECAM L
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Control typeButtons, Wireless
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, SER, SLK, SLV, SWE, TUR, UKR
Remote control typeRC833
Game featuresGame Master, Gamebar 2.0
AMD FreeSync typeFreeSync Premium Pro
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technologyTCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technologyDolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.5 W
Power consumption (typical)- W
Color depth10 bit
Screen shapeFlat
Response time5.7 ms
Display diagonal75 \
Display brightness1000 cd/m²
Display technologyQLED
Native aspect ratio16:9
Native refresh rate144 Hz
Peak luminance ratio65 %
LED backlighting typeFull-Array
Display diagonal (metric)189 cm
Motion interpolation technologyPPI (Picture Performance Index) 3900
Dynamic contrast ratio marketing nameMega Contrast
Package weightWeight of the packaged product in gram.
Cord length1.5 m
User memory20.9 GB
Battery weight15 g
Power plug typeType C
Warranty period2 year(s)
Country of originPoland
Battery technologyAlkaline
Processor frequency1.4 GHz
Processor architectureARM Cortex-A73
ProcessorMT5889
Internal memory22400 MB
Repairability index7.7
Weight and Dimensions IconWeight and Dimensions
Stand depth331 mm
Stand width480 mm
Depth (with stand)335 mm
Weight (with stand)28600 g
Depth (without stand)99 mm
Width (without stand)1671 mm
Height (without stand)965 mm
Weight (without stand)27520 g
