TCL 75C745 User Manual

16
Chapter 6 Other Functions
Press
on the remote control, select
(Settings) >
Channels & Inputs > Channels > Live TV Pause
,
then press
OK
to turn it on. Then exit to TV mode, press
to display Quick Settings panel, use Left/Right to
select
Live TV Pause
, and press
OK
to enter.
1.
Follow the directions on the screen to do the disk
setup if you use Live TV Pause for the first time.
2.
After the disk setup is done, Live TV Pause will
start, and the Live TV Pause menu displays on the
screen.
3.
When the Live TV Pause menu disappears and
only the timing of the Live TV Pause remains on
the screen, you can press
OK
to call out the Live
TV Pause menu and operate according to the on-
screen prompt.
4.
Press
button to stop the Live TV Pause and exit.
Notes:
- This feature is available only for digital channels.
- Before you plug the USB drive to TV, make sure
you have backed up the data on the drive to avoid
unforeseen malfunction and data loss.
- We recommend that you use a USB drive with at
least 1GB free space and a disk speed faster than
5.0MB/sec.
- The bigger the USB drive free space for Live TV
Pause, the bigger the recording length.
PVR
(
Personal Video Recorder)
(* Available according to the software version)
Allows you to record your favourite TV programs. Before
you use the function, connect a USB drive to the TV
rst.
Note:
The feature is available only in selected products
and, due to specific TV network limitations and country
technical requirements, might not be available in
product or place of installation. Feature might also be
blocked by TV network due to copyright protection (HD
content, recording protection).
1.
Press
on the remote control
, select
(Settings)
> Channels & Inputs > Channels > PVR
.
2.
Press
OK/Right
to enter and select
Record
. It starts
to record automatically.
3.
Press
blue
button to access
Settings
and use
Up/
Down/Left/Right
to adjust the recording duration.
4.
Press
OK
or
to stop recording manually,
the recorded file will be saved. In normal
operation, the recording will stop automatically
when the recording duration expires.
Note:
To access the blue button or
, you need to
press
button on the remote control to display the
virtual remote control keyboard rst.
5.
In recording, the PVR mini panel will also show on
the screen to indicate the recording progress.
6.
To watch the recorded program, exit PVR mode first.
Using Teletext
Selecting Decoding Page Language
1.
Press
on the remote control, select
(Settings)
> Channels & Inputs > Channels > Teletext >
Decoding Page Language
and press
OK/Right
to
enter.
2.
Press
Up/Down
to select a proper type of language
in which Teletext will display and press
OK
to
conrm.
3.
Press
to return to the previous menu.
Digital Teletext Language
On digital TV channels, depending on the broadcaster,
you may be able to enjoy a service with multiple initial
Teletext pages in di󰀨erent languages. This function
allows you to select an available language as primary
language, which relates to di󰀨erent initial Teletext
pages.
1.
Press
on the remote control, select
(Settings) >
Channels & Inputs >Channels > Teletext > Digital
Teletext Language
and press
OK/Right
to enter.
2.
Press
Up/Down
to select a language and press
OK
to conrm.
3.
Press
to return to the previous menu.
Variable Refresh Rate
Variable Refresh Rate is a feature that will allow smooth
gaming and eliminate screen tearing. The refresh rate
can dynamically change to up to 144hz. (
Note:
To use
this function,
Game Master
needs to be set to
Auto
or
On
.)
Under source of HDMI1, HDMI2, HDMI3 or HDMI4 (the
number of HDMI socket on the TV will vary according to
TV model).
Notes:
- 4K@144Hz is only available on HDMI 1. PC
Graphics card must be able to output 144Hz, please
check your graphics card specications.
- 4K@120Hz is only available on HDMI 1 or HDMI 2.
- You need to make sure your Games Console or PC
support Variable Refresh Rate, and you may need
to check your games console settings to activate
the function.
- The game/content also will need to support Variable
Refresh Rate, and you may also need to check the
settings within the game.
Live TV Pause
(* Available according to the software version)
Allows you to pause, fast forward and rewind live TV,
so you don’t have to miss any part of your favourite
programs. Before you use the function, connect a
USB drive to the TV rst. For the rst time, you should
complete the disk setup for the USB drive.

TCL 75C745 Specifications

General

DVI port	No
Headphone outputs	1
RF connector type	F, IEC
RF ports quantity	2
HDMI ports quantity	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial out	0
Audio Return Channel (ARC)	Yes
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
Video apps	Amazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Smart modes	Sports
Operating system version	11.0
App distribution platform	Google Play
Operating system installed	Google TV
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.2
Audio decoders	DTS, Dolby Atmos, Dolby Digital, DTS Virtual:X, DTS-HD, Dolby Digital AC4, Dolby TrueHD
RMS rated power	30 W
Audio output channels	2.0 channels
Equalizer bands quantity	7
Pallet width	1900 mm
Pallet net height	1300 mm
Pallet net length	800 mm
Pallet net weight	178400 g
Quantity per truck	168 pc(s)
Quantity per pallet	4 pc(s)
Master (outer) case width	1843 mm
Master (outer) case height	1120 mm
Master (outer) case length	187 mm
Master (outer) case weight	39120 g
Number of layers per pallet	1 pc(s)
Number of pallets per truck	42 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292519629
Maximum number of stacking cartons	2 pc(s)
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Browser supported	-
Bluetooth profiles	A2DP, HID
Stand type	Center stand
Product color	Black
Heavy metals free	Cd (cadmium)
Panel mounting interface	400 x 300 mm
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Analog signal format system	NTSC, PAL BG, PAL DK, PAL I, PAL L, SECAM B/G, SECAM D/K, SECAM L
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Control type	Buttons, Wireless
Programming period	8 day(s)
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, SER, SLK, SLV, SWE, TUR, UKR
Remote control type	RC833
Game features	Game Master, Gamebar 2.0
AMD FreeSync type	FreeSync Premium Pro
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technology	TCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technology	Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
Color depth	10 bit
Screen shape	Flat
Response time	5.7 ms
Display diagonal	75 \
Display brightness	1000 cd/m²
Display technology	QLED
Native aspect ratio	16:9
Native refresh rate	144 Hz
Peak luminance ratio	65 %
LED backlighting type	Full-Array
Display diagonal (metric)	189 cm
Motion interpolation technology	PPI (Picture Performance Index) 3900
Dynamic contrast ratio marketing name	Mega Contrast
Package weight	Weight of the packaged product in gram.
Cord length	1.5 m
User memory	20.9 GB
Battery weight	15 g
Power plug type	Type C
Warranty period	2 year(s)
Country of origin	Poland
Battery technology	Alkaline
Processor frequency	1.4 GHz
Processor architecture	ARM Cortex-A73
Processor	MT5889
Internal memory	22400 MB
Repairability index	7.7

Weight and Dimensions

Stand depth	331 mm
Stand width	480 mm
Depth (with stand)	335 mm
Weight (with stand)	28600 g
Depth (without stand)	99 mm
Width (without stand)	1671 mm
Height (without stand)	965 mm
Weight (without stand)	27520 g
