Remote Control Functions
Most of your television's functions are available via the menus that appear on the screen. The remote control(s)
supplied with your set can be used to navigate through the menus and to congure all the general settings.
Notes:
1.Figures and illustrations in this operation manual are provided for reference only and may dier from actual product
appearance. 2.The remote control type may be changed without notice, please refer to the remote control attached
with your TV. 3.Certain function may not be available for some models.
Connections and Setup
Circular
D-Pad
OK
To switch the sound o󰀨 and back on.
Standby / quit standby.
Add an entity to Watchlist in Google TV mode, and
display the TV list in DTV mode or future functions.
Press the Assistant button on your remote to talk
to the Google Assistant.
(Available only in Google
TV mode and when the network connection works
normally.)
To display the dashboard menu.
Circular D-Pad
Navigation direction buttons (
Up/Down/Left/Right
).
OK
To conrm an entry or selection.
To return to the previous menu or quit an app.
To access the Google TV homepage.
To access Electronic Program Guide.
(only available
for digital channels.)
To select input source.
/
To control the volume.
P+/P
-
To change channels.
To display and edit the quick settings panel.
To display the quick panel.
To pop up the virtual remote control keyboard when
available.
To open TCL home on screen.
To access Netix.
To access Stan.
To access Prime video.
To access Disney.
To access YouTube.
To access TCL Channel.
Google and Google TV are
trademarks of Google LLC.
Notes:
- Certain function may be accessed from the virtual remote control
keyboard only, please press
button on the remote to display it and
operate accordingly.
- The App buttons may dier depending on the model. The App
button is used for accessing the corresponding App.
-
How to Use the Remote Control
a. Before using the Google Assistant button, you must nish pairing the remote with the TV rst.
b. This Google Assistant function is only available for content search from certain apps.
c. Set languages in the
(Settings) > System > Language
to your local language or o󰀩cial language to en-
hance voice search successfully.

TCL 75C745 Specifications

General

DVI port	No
Headphone outputs	1
RF connector type	F, IEC
RF ports quantity	2
HDMI ports quantity	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial out	0
Audio Return Channel (ARC)	Yes
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
Video apps	Amazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Smart modes	Sports
Operating system version	11.0
App distribution platform	Google Play
Operating system installed	Google TV
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.2
Audio decoders	DTS, Dolby Atmos, Dolby Digital, DTS Virtual:X, DTS-HD, Dolby Digital AC4, Dolby TrueHD
RMS rated power	30 W
Audio output channels	2.0 channels
Equalizer bands quantity	7
Pallet width	1900 mm
Pallet net height	1300 mm
Pallet net length	800 mm
Pallet net weight	178400 g
Quantity per truck	168 pc(s)
Quantity per pallet	4 pc(s)
Master (outer) case width	1843 mm
Master (outer) case height	1120 mm
Master (outer) case length	187 mm
Master (outer) case weight	39120 g
Number of layers per pallet	1 pc(s)
Number of pallets per truck	42 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292519629
Maximum number of stacking cartons	2 pc(s)
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Browser supported	-
Bluetooth profiles	A2DP, HID
Stand type	Center stand
Product color	Black
Heavy metals free	Cd (cadmium)
Panel mounting interface	400 x 300 mm
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Analog signal format system	NTSC, PAL BG, PAL DK, PAL I, PAL L, SECAM B/G, SECAM D/K, SECAM L
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Control type	Buttons, Wireless
Programming period	8 day(s)
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, SER, SLK, SLV, SWE, TUR, UKR
Remote control type	RC833
Game features	Game Master, Gamebar 2.0
AMD FreeSync type	FreeSync Premium Pro
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technology	TCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technology	Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
Color depth	10 bit
Screen shape	Flat
Response time	5.7 ms
Display diagonal	75 \
Display brightness	1000 cd/m²
Display technology	QLED
Native aspect ratio	16:9
Native refresh rate	144 Hz
Peak luminance ratio	65 %
LED backlighting type	Full-Array
Display diagonal (metric)	189 cm
Motion interpolation technology	PPI (Picture Performance Index) 3900
Dynamic contrast ratio marketing name	Mega Contrast
Package weight	Weight of the packaged product in gram.
Cord length	1.5 m
User memory	20.9 GB
Battery weight	15 g
Power plug type	Type C
Warranty period	2 year(s)
Country of origin	Poland
Battery technology	Alkaline
Processor frequency	1.4 GHz
Processor architecture	ARM Cortex-A73
Processor	MT5889
Internal memory	22400 MB
Repairability index	7.7

Weight and Dimensions

Stand depth	331 mm
Stand width	480 mm
Depth (with stand)	335 mm
Weight (with stand)	28600 g
Depth (without stand)	99 mm
Width (without stand)	1671 mm
Height (without stand)	965 mm
Weight (without stand)	27520 g
