TECHNICAL SPECIFICATION
Model
iQool9 – V4
iQool9B
iQool12 – V4
iQool12B
iQool18 – V4
iQool18B
iQool24 – V4
iQool24B
Rated voltage and frequency
(Ph-V-Hz)
1Ph/220-
240V~/50Hz
1Ph/220-
240V~/50Hz
1Ph/220-
240V~/50Hz
1Ph/220-
240V~/50Hz
Fuse Required
13A
13A
13A
16A
Mode
Cooling
Heating
Cooling
Heating
Cooling
Heating
Cooling
Heating
Rated capacity (W)
2600
(940～
3320)
2610
(940～
3380)
3400
(1000～
3770)
3420
(1000～
3810)
5130
(1250~
5920)
5230
(1350~
6280)
6810
(1830~
7810)
6870
(1850~
7930)
Power input (W)
750
(240～
1230)
752
(240～
1280)
1010
(290～
1320)
948
(290～
1400)
1530
(330～
2250)
1550
(340～
2350)
1980
(410~
2800)
2050
(420~
3000)
Current input (A)
4.0(1.2~
6.3)
4.1(1.2~
6.5)
4.7(1.5
～6.7)
4.5(1.5
～7.0)
7.2(1.7~
10.8)
7.3(1.7~
12.0)
8.9(2.3~
12.5)
9.0(2.3
~13.7)
SEER/SCOP(W/W)
6.5/A++
4.0/A+
6.5/A++
4.0/A+
6.3/A++
4.0/A+
6.5/A++
4.1/A+
Nominal load (kW)
2.60
2.61
3.40
3.42
5.13
5.23
6.81
6.87
Balance point temperature
heating (
o
C)
/
-7
/
-7
/
-7
/
-7
Min. outdoor operating
temperature (
o
C)
/
-15
/
-15
/
-15
/
-15
Thermostat-off mode (W)
35
35
45
45
Standby mode (W)
2
2
2.5
2.5
Off mode (W)
0
0
0
0
Annual consumption (kW)
140
735
183
840
283
1575
366
1878
Copper Pipe Type length
5m
5m
5m
5m
Liquid side / Gas side
(mm/inch)
6.35 (1/4) + 9.52
(3/8)
6.35 (1/4) + 9.52
(3/8)
6.35 (1/4) + 9.52
(3/8)
6.35 (1/4) + 12.7
(1/2)
Max. refrigerant pipe length
25m
25m
25m
25m
Max. elevation
10m
10m
10m
10m
Interconnecting Cable
4×1.0mm²
4×1.0mm²
4×1.5mm²
4×0.75mm²
Fuse Rating
4A on indoor PCB
4A on indoor PCB
4A on indoor PCB
4A on indoor PCB
Moisture Removal (L/h)
0.9
1.1
1.5
1.8
Indoor
Air Flow (m
3
/h)
420
550
800
970/980
Dimensions (L*W*H)
(mm)
698x255x190
777x250x205
910×292×205
1010×315×220
Packaging (L*W*H
(mm)
764x325x257
850x320x275
979×372×277
1096×390×297
Net / Gross weight
(Kg)
6.5/8.5
8.5/10.5
10/13
13/16
Noise – Sound
pressure level (dB/A)
22~40
22~40
27~43
30~44
Noise – Sound
power level (dB/A)
32~50
32~50
37~53
40~54
