TCL Sweeva 6500 User Manual

System resetting
Relocation and regeneration of a map
Operating Instructions
EN
20
Map management
Real-time drawing of a room map
In the standby mode, press and hold the button for 15
seconds to reset the system.
After resetting the system, the robot vacuum will lose the
map and the original settings including the virtual
boundary.
Real-time drawing of a room map can help you easily
understand the cleaning path and environment. The map will
be updated in real time during each cleaning to ensure
normal navigation.
To generate a complete room map:
a. Remove objects that may block or seize the robot
vacuum;
b. After the map is generated, please do not move the
charging dock or disconnect the power supply.
When the robot vacuum is moved or the surrounding environ-
ment changes significantly, the robot vacuum will try to
relocate itself and may regenerate a map to match with the
surrounding environment. Details are as follows:
a. If the relocation is successful, the robot vacuum will
resume cleaning;
b. If the relocation fails, the robot vacuum will regenerate a
map to ensure normal navigation for new cleaning; if the
original map has a virtual boundary (forbidden zone), the
robot vacuum will not start new cleaning to avoid crossing
the forbidden zone.
Make sure that the robot vacuum starts cleaning from the
charging dock every time.
During cleaning, do not move the robot vacuum frequently.
If you has moved the robot vacuum, please put it back to
its original position.
Zone cleaning mode (only applicable to the App)
You can use the mobile APP to set three cleaning modes:
Room cleaning, area cleaning and spot cleaning.
Only after the main machine successfully creates a map,
zone cleaning can be started.
*
*

TCL Sweeva 6500 Specifications

General

Wi-Fi	Yes
Noise level	65 dB
Wet mopping	No
Navigation type	Laser Distance Sensor (LDS)
Integrated sensors	Drop sensor, Non-contact distance sensor
Water tank capacity	- L
Dust capacity (base)	4 L
Programming function	-
Dust capacity (total)	0.5 L
Base station functions	Charging, Purification
Vacuum cleaner programs	Pin-n-Go, Area, Auto, Edge, Random room, Repeat, Spot, Turbo
Threshold climbing (max)	20 mm
Air filtration stages quantity	4
Cord length	- m
Charging time	- h
Battery voltage	- V
AC input voltage	220 - 240 V
Battery capacity	5000 mAh
AC input frequency	50 Hz
Filter	HEPA Filter (Washable)
Filter type	HEPA
Package weight	8.9 kg
Number of filters	1 pc(s)
Dimensions (LxWxH)	342 x 342 x 95 mm
Maximum input power	- W
Accessories included	Side Brush×1, Roller Brush ×1 , Filter ×1
Package dimensions (LxWxH)	340 x 431 x 394 mm
Shape	Round
Product color	Black
Dust container type	Dust bag
8900 g	Weight of the packaged product in gram.
Package depth	340 mm
Package width	431 mm
Package height	394 mm
Battery life	3 h

Weight and Dimensions

Width	342 mm
Height	95 mm
Weight	6400 g
