TCL Air Conditioner Service Manual
10.7 THERMISTOR TEMPERATURE CHARACTERISTICS
1. Indoor unit and outdoor exchange temperature and outside air temperature sensor temperature
characteristics
TEMP.
(℃)
Resistance
(k Ohm)
Voltage of
resistance
TEMP.
(℃)
Resistance
(k Ohm)
Voltage of
resistance
TEMP.
(℃)
Resistance
(k Ohm)
Voltage of
resistance
-30 63.513 4.628 15 7.447 2.968 60 1.464 1.115
-29
60.135 4.609
16
7.148 2.918
61
1.418 1.088
-28
56.956 4.589
17
6.863 2.868
62
1.374 1.061
-27 53.963 4.568 18 6.591 2.819 63 1.331 1.035
-26
51.144 4.547
19
6.332 2.769
64
1.290 1.009
-25
48.488 4.524
20
6.084 2.720
65
1.250 0.984
-24 45.985 4.501 21 5.847 2.671 66 1.212 0.960
-23 43.627 4.477 22 5.621 2.621 67 1.175 0.936
-22 41.403 4.452 23 5.404 2.572 68 1.139 0.913
-21
39.305 4.426
24
5.198 2.524
69
1.105 0.890
-20
37.326 4.399
25
5.000 2.475
70
1.072 0.868
-19 35.458 4.371 26 4.811 2.427 71 1.040 0.847
-18
33.695 4.343
27
4.630 2.379
72
1.009 0.825
-17 32.030 4.313 28 4.457 2.332 73 0.979 0.805
-16 30.458 4.283 29 4.292 2.285 74 0.950 0.785
-15
28.972 4.252
30
4.133 2.238
75
0.922 0.765
-14 27.567 4.219 31 3.981 2.192 76 0.895 0.746
-13 26.239 4.186 32 3.836 2.146 77 0.869 0.728
-12 24.984 4.152 33 3.697 2.101 78 0.843 0.710
-11
23.795 4.117
34
3.563 2.057
79
0.819 0.692
-10
22.671 4.082
35
3.435 2.012
80
0.795 0.675
-9 21.606 4.045 36 3.313 1.969 81 0.773 0.658
-8
20.598 4.008
37
3.195 1.926
82
0.751 0.641
-7
19.644 3.969
38
3.082 1.883
83
0.729 0.625
-6 18.732 3.930 39 2.974 1.842 84 0.709 0.610
-5 17.881 3.890 40 2.870 1.800 85 0.689 0.595
-4 17.068 3.850 41 2.770 1.760 86 0.669 0.580
-3
16.297 3.808
42
2.674 1.720
87
0.651 0.566
-2
15.565 3.766
43
2.583 1.681
88
0.633 0.552
-1
14.871 3.723
44
2.494 1.642
89
0.615 0.538
0
14.212 3.680
45
2.410 1.604
90
0.598 0.525
1
13.586 3.635
46
2.328 1.567
91
0.582 0.512
2
12.991 3.590
47
2.250 1.530
92
0.566 0.499
3
12.426 3.545
48
2.174 1.495
93
0.550 0.487
4
11.889 3.499
49
2.102 1.459
94
0.535 0.475
5
11.378 3.452
50
2.032 1.425
95
0.521 0.463
6
10.893 3.406
51
1.965 1.391
96
0.507 0.452
7
10.431 3.358
52
1.901 1.357
97
0.493 0.441
8 9.991 3.310 53 1.839 1.325 98 0.480 0.430
9
9.573 3.262
54
1.779 1.293
99
0.467 0.419
10 9.174 3.214 55 1.721 1.262 100 0.455 0.409
11
8.795 3.165
56
1.666 1.231
12
8.433 3.116
57
1.613 1.201
13 8.089 3.067 58 1.561 1.172
14
7.760 3.017
59
1.512 1.143
41
