TCL Air Conditioner Service Manual
18
Indoor Unit- TAC-24CF/E
No. Part No. Part Name Q’ty Remark
1 1070740403 Operation Panel 1
2 1070520117 Temperature Display Lens 1
3 1070520118 Display lens 1
4 1090520104 Display PCB 1
5 1070520102 Top Panel 1
6 1070520103 Horizontal Vane 1
7 1070520106 Vertical Vane 2
8 1070520148 Vertical Vane Connect Rod 1
9 1070520107 Horizontal Vane Connect Rod 3
10 1170010008 Stepping Motor 1
11 1150520101 Out Fan Casing Foam 1
12 1150520102 Heat Insulation Board 2
13 1074090101 Copper Pipe Cover 1
14 1200710102 Rubber Water Drainage1 1
15 1200710101 Rubber Water Drainage2
16 1210710101 Evaporator Assembly 1
17 1210520115 Right Plate 1
18 1210520113 Top Plate 1
19 1210520114 Left Plate 1
20 1070520101 Base 1
21 1170050002 Fan Motor 2
22 1070010008 Centrifugal Fan 2
23 1150520104 Volute Casing 1
24 1074060115 Lead Flow Circle 1
25 1080520105 Electrical Parts Box 1
26 1074020122
1074020914
Cable Clamp1
Cable Clamp2
1
1
27 1170200026 Terminal 1
28 1170100027 Fan Motor Capacitor
29 1170240002 Transformer 1
30 1090710301 Main PCB 1
31 1170520103 Pipe Temp. Sensor & Room
Temp. Sensor Assembly
1
32 1080520106 Electrical Parts Box Cover 1
33 1070520113 Left Grille 1
34 1070520111 Below Panel 1
35 1070520112 Right Grille 1
36 1070520149 Left Right Grille Buckle 2
37 1070520147 Air Filter 1
To Next Page
