TCL Air Conditioner Service Manual
3
Technical Specifications
Model No. TAC-24CS/F TAC-24CHS/F
Type Cooling Only Heating Pump
Control type Remote Remote
Rated cooling capacity Btu/h 24000 24000
Rated heating capacity Btu/h N/A 25000
EER for cooling Btu/h.w 9.6 10.3
COP for heating W/W N/A 3.2
Moisture removal Liters/h 2.2 2.2
High dB(A) 48 48
Med. dB(A) 46 46
Indoor noise level at
cooling
Low dB(A) 40 40
Outdoor noise level dB(A) 58 58
Electrical Data
Power supply 220-240V~/50Hz
Voltage Range V
Cooling A 11.5 12.0
Rated current
Heating A N/A 10.0
Cooling W 2400 2300
Rated input
Heating W N/A 2100
Refrigerating System
Refrigerant/Charge Gram R22/1450g R22/2350g
Type Rotary Rotary
Model ------------------ -----------------
LRA A ------ -------
Compressor
MFG ----------------- -----------------
Evaporator Louver fin and Grooved tube type (φ7)
Condenser Corrugated fin and Grooved tube type (φ9.53)
Expansion device Capillary tube
Defrosting system Microcomputer controlled reverse system
Fan System
Indoor air circulation m
3
/h 1200 1200
Indoor fan type Cross flow Cross flow
Cooling rpm 480/430/380 480/430/380
Heating rpm N/A 480/430/380
Dry rpm 380 380
Indoor fan speed
H/M/L
Sleep rpm 380 380
Indoor fan motor output W 76 76 76
Outdoor air circulation m
3
/h --- ---
Outdoor fan type Propeller fan Propeller fan
Outdoor fan speed rpm 850 850
Outdoor fan motor output W 76 76
Connections
Refrigerant coupling Flare type
Gas Inches 3/8 3/8
Connecting Pipe
Liquid Inches 5/8 5/8
Connecting Wiring
Size × Core
number
Drainage Pipe O.D 16mm
Others
Suitable area m
2
35~48 35~48
Indoor mm 480×1730×330 710×250×179 Net dimensions
(W x H x D)
Outdoor mm 860×640×310 600×500×232
Indoor kg 36 7.5
Net weight
Outdoor kg 56 25
Indoor mm 588×1825×425 805×325×270 Packing dimensions
(W x H x D)
Outdoor mm 990×720×420 745×352×542
Indoor kg 45 10
Gross weight
Outdoor kg 66 29
Loading Capacity 40’/40’HC 32/75/84 32/75/84
