TCL Air Conditioner Service Manual
22
Part List
Outdoor Unit- TAC-24CF/E
No. Part No. Part Name Q’ty Remark
1 1084530501 Grille 1
Optional
2 1084530504 Top Cover 1
3 1210710303 Condenser 1
4 1084530510 Outdoor Motor Supporter 1
5 1170040063 Outdoor Motor 1
6 1070030017 Propeller Fan 1
7 1084530516 Left Plate 1
8 1074530502 Left Handle 1
9 1084530514 Front Plate 1
10 1084530515 Fan Guard 1
11 1124560206 Three-way Connecting Pipe 1
12 1124560201 Suction Pipe 1
13 1214561809 Base 1
14 1100060013 Compressor And It Accessories 1
15 1084530503 Right Plate 1
16 1084530502 Valve Supporter 1
17 1120120011 Two-way Valve 1
18 1120130013 Three-way Valve 1
19 1074530503 Electrical Box Cover 1
20 1080010004 Capacitor Strip 1
21 1074060118 Cable Clamp 1
22 1170200026 Terminal 1
23 1170100007 Compressor Capacitor 1
24 1170100030 Fan Motor Capacitor 1
25 1084561802 Electrical Parts Box 1
26 1174561801 AC Contactor 1
27 1120710307 Discharge Pipe 1
28 1210710302 Capillary Assembly 1
29 1190070003 Base Carton 1
30 1190070013 Cabinet Carton 1
31 1190070004 Cover Carton 1
Not show in the explosion
