TCL TACM2O-28HIA

Air Conditioner Service Manual
18
Wall split type- TACM-12HRIA/EW
No.
Part No.
Part Name
Q’ty
Remark
1
1080030021
Installation Plate
1
2
210737661G
Base
1
3
210701883
Vertical Vane Assembly
2
4
210738167
Left Vertical Vane Connector
1
5
210737671
Vane
1
6
210737666
Cross Fan
1
7
1070100010
Bearing Mount
1
8
211236178G
Evaporator
1
9
210737669
Face Frame
1
10
210701846
Screw Cover
1
11
210703004
Air Filter
2
12
1070250120
Display PCB Box
1
13
1090250119AQ
Display PCB
1
14
210738178C
Front Panel
1
15
210737654
Electrical Box Cover
1
16
210900478A
Terminal
1
17
210736912
Cable Clamp
1
18
210900333
Indoor Sensor Assembly
1
19
210901628A
Main PCB
1
20
210736831
Electrical Box
1
21
1170030067G
Indoor Motor
1
22
210737665
Indoor Motor Cover
1
23
210738168
Right Vertical Vane connector
1
24
210737668
Step Motor connector
1
25
210900129
Step Motor
1
26
210738225
Step Motor Supporter
1
27
210737091
Drainage Hose
1
28
210736813
In And Out Pipe Fixer
1
29
1170020011
Vane Motor
1
30
210901521B
Remote Controller
1
Not shown in Explosion view
31
1190540002ACX
Indoor Carton
1
32
211363352
Left Foaming
1
33
211363353
Right Foaming
1
