Air Conditioner Service Manual
26
DUCT TYPE- :TDCM-07HRIA, TDCM-09HRIA
NO.
Part NO.
Part Name
Pty
Remark
1
230801045
Front plate
1
2
230801031
Indoor chassis
1
3
230700620
Drain pan
1
4
230801046
Inlet plate
1
5
231202769A
Evaporator
1
6
230801080
Left plate
1
7
230800420
Installation holder
4
8
230801118
Space plate
1
9
230801442
Motor supporter
1
10
230700626
Down Vortex
2
11
230801048
Indoor fan
2
12
230700628
Up Vortex
2
13
230801117
Top plate
1
14
230800425A
Left motor holder
1
15
230901635
Indoor motor
1
16
230800426A
Right motor holder
1
17
230801115
Electrical box installation plate
1
18
230801038
Electrical box
1
19
230901484A
Main PCB
1
20
230901784A Inductor
1
21
230900237
Display PCB
1
22
230801039
Electrical box cover
1
23
230801090
Pipe cover plate
1
24
230801081
Right plate
1
25
210900414A
Remote controller
1
Not shown in explosion view
26
230901285
Indoor pipe sensor
1
27
3160130011
Indoor room sensor
1
