Air Conditioner Service Manual
21
Wall split type- TACM-12HRIA/E1
No.
Part No.
Part Name
Q’ty
Remark
1
1080030021
Installation Plate
1
2
210737661D
Base
1
3
210701880C
Vertical Vane Assembly
2
4
210737666
Cross Fan
1
5
1070100010
Bearing Mount
1
6
211236178G
Evaporator
1
7
210737669
Face Frame
1
8
210701846
Screw Cover
2
9
210737672
Vane
1
10
210703004
Air Filter
2
11
210705767
Display PCB Box
1
12
210901127S
Display PCB
1
13
210754504
Front Panel
1
14
210737654
Electrical Box Cover
1
15
210736912
Cable Clamp
1
16
210900478A
Terminal
1
17
210901628A
Main PCB
1
18
210900333
Indoor Sensor Assembly
1
19
210736831
Electrical Box
1
20
1170030067G
Indoor Motor
1
21
210737665
Indoor Motor Cover
1
22
210701101AA
Drainage Hose
1
23
1170020011
Vane Motor
1
24
210736813
In And Out Pipe Fixer
1
25
210901521B
Remote Controller
1
Not shown in Explosion view
26
1190540002ACY
Indoor Carton
1
27
211370970
Left Foaming
1
28
211370971
Right Foaming
1
