TCL TACM2O-28HIA

Air Conditioner Service Manual
23
Cassette type- TQCM-12HRIA,TQCM-12HRIA
NO.
Part NO.
Part Name
Qty
Remark
1
/
Indoor chassis
1
2
230900366
Indoor motor
1
3
230701325
Indoor fan
1
4
/
Base of evaporator
1
5
/
Evaporator
1
6
/
Capacitor of indoor motor
1
7
1170200061
Terminal
1
8
/
Drain pan
1
9
230701669
Panel
1
10
/
Vane
1
11
230904459
Display PCB
1
12
230904486
Swing motor
4
13
230901784A
Inductor
1
14
230901484A
Indoor main PCB
1
15
230901539
Pump
1
16
230901538
Water level switch
1
17
210900414A
Remote controller
1
Not shown in explosion view
18
3160130006
Indoor pipe sensor
1
19
3160130011
Indoor room sensor
1
