TCL TACM2O-28HIA User Manual

Air Conditioner Service Manual
28
DUCT TYPE- :TDCM-18HRIA
NO.
Part NO.
Part Name
Pty
Remark
1
230801044
Front plate
1
2
230801032
Indoor chassis
1
3
230700621
Drain pan
1
4
230801052
Inlet plate
1
5
231202183A
Evaporator
1
6
230801080
Left plate
1
7
230800420
Installation holder
4
8
230801116
Space plate
1
9
230801443
Motor supporter
1
10
3070060021
Down Vortex
2
11
3070020001A
Indoor fan
2
12
3070060020
Up Vortex
2
13
230801079
Top plate
1
14
230800425A
Left motor holder
1
15
230901635
Indoor motor
1
16
230800426A
Right motor holder
1
17
230801115
Electrical box installation plate
1
18
230801038
Electrical box
1
19
230901484A
Main PCB
1
20
230901784A
Inductor
1
21
230900237
Display PCB
1
22
230801039
Electrical box cover
1
23
230801090
Pipe cover plate
1
24
230801081
Right plate
1
25
210900414A
Remote controller
1
Not shown in explosion view
26
3160130004
Indoor pipe sensor
1
27
3160130011
Indoor room sensor
1
