Air Conditioner Service Manual
15
Parts List
Indoor Unit- TFC-24HRA
No.
Part No.
Part Name
Q’ty
Remark
1
210701315
Inside Base
1
2
1080510051AA
Right Plate
1
3
1080510067
Back Plate
1
4
1200710101
Rubber Water Drainage
1
5
1080510052AA
Left Plate
1
6
1110050531
Evaporator
1
7
1080520226
Top Plate
1
8
210702134
Pipe Cover
2
9
1070520508
Water Drainage
1
10
1150720004
Out Blow Casing Foam
1
11
1150720005
Heat insulation board
2
12
1070520106
Vertical Vane
5
13
1170010008
Synchronization Motor
1
14
1070710418
Horizontal Vane
6
15
1070710417
Up Panel
1
16
1080520103
Middle Supporter
1
17
1080710302
Heat insulation board Cover
1
18
1090520136
Display PCB
1
19
1070710421
Display PCB Supporter
1
20
1070710014
Display PCB Cover
1
21
1070710424
Spring
1
22
1070710423
Button
1
23
1020710001
Ornamental Board
1
24
1070710414
Down panel
1
25
1070710010
Fastener
1
26
1070520147
Air Filter
1
27
1170230009
Indoor Sensor
1
28
1074060115
Lead Flow Circle
1
29
1080520218
Inside Electrical Box Cover
1
30
1070010019AA
Centrifugal Fan
1
31
1170240002
Transformer
1
32
1170050002
Indoor Motor
1
33
1170100027A
Fan Motor Capacitor
1
34
1170200053
Terminal
1
35
210900265AN
Main PCB
1
36
1150520215
Volute Casing
1
37
1300521036
Inside Electrical Box
1
38
210900414A
Remote Controller
1
Not shown in Explosion view
39
210701101
Drainage hose
1
40
1170120009
Power supply cord
1
41
211300948GF
Indoor Carton
1
