TCL TFC-24HRA

Air Conditioner Service Manual
16
Indoor Unit- TFC-48HRA
No.
Part No.
Part Name
Q’ty
Remark
1
1071200023
Inside Base
1
2
1081200114
Right Plate
1
3
1301200025
Back Plate
1
4
1204090101
Rubber Water Drainage
1
5
1081200116
Left Plate
1
6
1110050374
Evaporator
1
7
1071200024
Top Plate
1
8
210702134
Pipe Cover
2
9
1154090101
Water Drainage
1
10
1151200001
Out Blow Casing Foam
1
11
1214090113
Heat insulation board
2
12
1071200014
Vertical Vane
6
13
1170010008
Synchronization Motor
1
14
1071200012
Horizontal Vane
6
15
1071200011
Up Panel
1
16
1084090101
Middle Supporter
1
17
1090520136
Display PCB
1
18
1070710422
Display PCB Supporter
1
19
1070710014
Display PCB Cover
1
20
1070710424
Spring
1
21
1070710423
Button
1
22
1020710001
Ornamental Board
1
23
1071200021
Down panel
1
24
1070710016
Fastener
1
25
1070300003
Air Filter
1
26
1170230009
Indoor Sensor
1
27
1074090102
Lead Flow Circle
1
28
1084090113
Inside Electrical Box Cover
1
29
1070010004AA
Centrifugal Fan
1
30
1170240002
Transformer
1
31
1170030010
Indoor Motor
1
32
230901275
Fan Motor Capacitor
1
33
1170200058
Terminal
1
34
210900265BB
Main PCB
1
35
1154090102
Volute Casing
1
36
1081200155
Inside Electrical Box
1
37
210900414A
Remote Controller
1
Not shown in Explosion view
38
210701101AA
Drainage hose
1
39
1170120051
Power supply cord
1
40
1190510005KE
Indoor Carton
1
