TCS 3000 User Manual

24
Total Control Systems www.tcsmeters.com
D) Add New Before you can calibrate the register, you must enter a product. Select Add New
and use the keypad to enter a product (e.g. LPG, Fuel Oil, Aviation Gasoline, etc.).
Once you’ve entered your product, press ENTER.
- All parameters for a New Product MUST be entered for the product to be
accepted by the TCS 3000. Follow pages 18 through 22, under Modify Parame-
ters to complete the Add New product setup. Once the new product parameters
have been entered, you will be required to calibrate the product.
NOTE: A new product MUST be calibrated for it to be available as an Active product.
Without calibration, the new product will only be seen in Product Settings LIST.
E) Remove Product To remove an unwanted product from the TCS 3000, select and press ENTER.
To confirm product removal, press MODE.
NOTE: You must first End Shift and then Deactivate the product under Product Set
tings.
F) Hose Charge Enable or Disable the Hose Charge at beginning of delivery. Adjustment to the Hose
Charge volume is made under the Product Hose Volume seen on page 21.
FLOW METER PULSE CHANNEL
2:1 Packing Gland (Standard)
TCS 3000 75/90 DEGREE MOUNT
1:1 Packing Gland
TCS 3000 75/90 DEGREE MOUNT
Direct Mount Pulser 100:1
TCS 3000 REMOTE MOUNT
700-20/25
Single 277.75 Pulses/USG 73.4 Pulses/LTR 555.5 Pulses/USG 146.8 Pulses/LTR 555.5 Pulses/USG 146.8 Pulses/LTR
Dual 555.5 Pulses/USG 146.8 Pulses/LTR 1111.0 Pulses/USG 293.6 Pulses/LTR 1111.0 Pulses/USG 293.6 Pulses/LTR
Quadrature 1111.0 Pulses/USG 293.6 Pulses/LTR 2222.0 Pulses/USG 587.2 Pulses/LTR 2222.0 Pulses/USG 587.2 Pulses/LTR
700-30/35
Single 102.9 Pulses/USG 27.2 Pulses/LTR 205.8 Pulses/USG 54.4 Pulses/LTR 205.8 Pulses/USG 54.4 Pulses/LTR
Dual 205.8 Pulses/USG 54.4 Pulses/LTR 411.6 Pulses/USG 108.8 Pulses/LTR 411.6 Pulses/USG 108.8 Pulses/LTR
Quadrature 411.6 Pulses/USG 108.8 Pulses/LTR 823.2 Pulses/USG 217.6 Pulses/LTR 823.2 Pulses/USG 217.6 Pulses/LTR
700-40/45
Single 37.1 Pulses/USG 9.8 Pulses/LTR 74.2 Pulses/USG 19.6 Pulses/LTR 74.2 Pulses/USG 19.6 Pulses/LTR
Dual 74.2 Pulses/USG 19.6 Pulses/LTR 148.4 Pulses/USG 39.2 Pulses/LTR 148.4 Pulses/USG 39.2 Pulses/LTR
Quadrature 148.4 Pulses/USG 39.2 Pulses/LTR 296.8 Pulses/USG 78.4 Pulses/LTR 296.8 Pulses/USG 78.4 Pulses/LTR
700-60/65
Single 18.55 Pulses/USG 4.9 Pulses/LTR 37.1 Pulses/USG 9.8 Pulses/LTR 37.1 Pulses/USG 9.8 Pulses/LTR
Dual 37.1 Pulses/USG 9.8 Pulses/LTR 74.2 Pulses/USG 19.6 Pulses/LTR 74.2 Pulses/USG 19.6 Pulses/LTR
Quadrature 74.2 Pulses/USG 19.6 Pulses/LTR 148.4 Pulses/USG 39.2 Pulses/LTR 148.4 Pulses/USG 39.2 Pulses/LTR
Total Control Systems - Meter Pulse Value Factors
FLOW METER PULSE CHANNEL
4:1 Packing Gland (Standard)
TCS 3000 75/90 DEGREE MOUNT
Direct Mount Pulser 100:1
TCS 3000 REMOTE MOUNT
700-15
Single 305.9 Pulses/USG 80.8 Pulses/LTR 1223.7 Pulses/USG 323.3 Pulses/LTR
Dual 611.6 Pulses/USG 161.6 Pulses/LTR 2446.4 Pulses/USG 646.3 Pulses/LTR
Quadrature 1223.2 Pulses/USG 323.4 Pulses/LTR 4892.8 Pulses/USG 1293.5 Pulses/LTR
FLOW METER
PULSE CHANNEL
TCS 3000 75/90 DEGREE MOUNT
Direct Mount Pulser 100:1
TCS 3000 REMOTE MOUNT
682-15
Single 200.0 Pulses/USG 52.85 Pulses/LTR 400.0 Pulses/USG 105.7 Pulses/LTR
Dual 400.0 Pulses/USG 105.7 Pulses/LTR 800.0 Pulses/USG 211.4 Pulses/LTR
Quadrature 800.0 Pulses/USG 422.8 Pulses/LTR 1600.0 Pulses/USG 422.8 Pulses/LTR
