TCS 3000 User Manual

42
Total Control Systems www.tcsmeters.com
PROBLEM PROBABLE CAUSE SOLUTION
Unit blows 7.5A fuse. +12VDC Baery line is
shorted to ground.
1. For safety reasons, remove the 4A, in-line fuse from the acces-
sory power cable.
2. Unscrew the 3 pin power connector. Inspect for stray wire
strands and visible shorts.
3. Inspect the full length of the power cable. Look for damaged
insulaon, which may cause shorng between the cable and
ground potenal (e.g. truck frame or chassis). If the power
cable is damaged, it must be replaced.
4. Replace the 7.5A fuse and re-install the wires into the terminal
Bd. connector.
5. If the 7.5A blows again, then replace the power cable.
6. If the 7.5A fuse blows aer replacing the power cable, then
replace the TCS3000 terminal circuit board.
Display is reading in reverse Pulse Channel TAHA1 and
TAHB1 are wired back-
wards
Switch Pulser wiring between Channel A and B.
Black display screen but
power LED indicator is on.
Sucient power to the
register, however there
may be a current draw
from the system that will
not allow the register dis-
play to power up properly.
1. Cycle power of the register
2. Allow diesel chassis glow plugs to properly charge before turn-
ing over the ignion.
3. Power On Time Relay may be required for installaon.
4. Contact factory for further support.
Time and Date reset to
10/28/13
Low Baery Power
Short on Baery
1. Go to Operaon Status under Reports and check internal
baery voltage. If under 2.75V, baery must be replaced.
2. Check that no wires are in contact with Baery. Time and Date
are reset if in contact and power is shuto. Use electrical tape
or heat shrink on bare wire to prevent from happening again.
3. If me and date reset each me you cycle power, change Time
Source from Controller to BIOS in Regional Sengs.
Display screen has mulple
colored lines.
Ribbon cable is not seated
properly.
1. Contact factory for further support.
2. Disassemble the front cover of the register to reseat the dis-
play ribbon cable.
Buons on my keyboard are
not acve.
Tacle buon has been
damaged.
1. Contact factory for further support.
2. Disassemble the front cover of the register to replace key-
board.
System One Error New Soware not com-
pable with exisng Firm-
ware
1. Press STOP/CANCEL to back out of a level and connue with
normal operaon of the register. This code detects soware
features that not compable with exisng rmware.
2. Some funcons will not operate (Addive Injecon, Dierenal
Pressure, etc.) under old Firmware.
3. Contact factory for Firmware upgrade.
Register reboots in Idle or
Delivery
Ground Short 1. Loose ground wire causing short. Check power distribuon box
and TCS 3000 register for loose grounds. Find and ghten.
2. Inadequate power due to current draw from hose reel or sole-
noid coil.
Operang System (OS) Error
Controller Com Error
Grub Error
Root Password Error
OS loading error during
boot up
1. OS loading errors occur during startup. Voltage spikes or cur-
rent draws during OS bootup can corrupt soware.
2. Contact factory for replacement.
HARDWARE/SOFTWARE TROUBLESHOOTING (CONTINUED)
