ZK300DC SWING GATE OPERATOR USER’S MANUAL
2
TABLE OF CONTENTS
Important Safety Information 3
Additional Features 3
Packing List 4
Specifications 5
Necessary Tools 5
Site Preparation 5
Mechanical / Installation 6
Electrical / Control Box Mounting 12
Electrical / Main Terminal Wiring 13
 Electric Lock 14
 Flashing Light 14
 External Button Switch 14
 Infrared Photocell 14
 Battery 14
Electrical / Setting 15
 Learn Remote Controls 15
 To Erase All Remote Controls 15
 Setting Open and Close Limit 15
 Setting Auto Close Time 15
 Setting Interval Time 15
 Setting obstruction force 15
Maintenance 16
Troubleshooting 16
