73
TS-67 Temperature (°C) versus Resistance (ohms) Data
For MP-3193, MP-2444, MP-2542, and MP-2996 (not pictured) 15 kΩ Thermistors
MP-2444MP-2444
MP-3193MP-3193
MP-2542MP-2542MP-2542
25.4
3.18
6.35 SQ.
3.94
Ø3.61
THRU
914.4
(2) 26 AWG STRANDED WIRE,
UL1430, IRRADIATED CROSS-LINKED
6.35
PVC INSULATION, ORANGE
ALUMINUM BLOCK
EPOXY FILL
