TS-141 Temperature (°C) versus Resistance (ohms) Data
For MP-3716 5 kΩ Thermistors
-60.0 701030.0 -30.0 88520.1 0.0 16330.0 30.0 4028.1 60.0 1244.0 90.0 458.2
-59.0 649576.4 -29.0 83208.0 1.0 15519.3 31.0 3860.6 61.0 1200.1 91.0 444.3
-58.0 602226.0 -28.0 78247.1 2.0 14753.6 32.0 3700.9 62.0 1158.0 92.0 431.0
-57.0 558627.3 -27.0 73612.3 3.0 14030.1 33.0 3548.8 63.0 1117.6 93.0 418.1
-56.0 518461.3 -26.0 69280.3 4.0 13346.2 34.0 3403.7 64.0 1078.8 94.0 405.6
-55.0 481437.4 -25.0 65229.5 5.0 12699.6 35.0 3265.3 65.0 1041.6 95.0 393.6
-54.0 447291.6 -24.0 61440.2 6.0 12088.0 36.0 3133.3 66.0 1005.8 96.0 382.0
-53.0 415783.4 -23.0 57893.9 7.0 11509.4 37.0 3007.4 67.0 971.4 97.0 370.8
-52.0 386693.4 -22.0 54573.8 8.0 10961.8 38.0 2887.1 68.0 938.4 98.0 359.9
-51.0 359822.2 -21.0 51464.2 9.0 10443.4 39.0 2772.4 69.0 906.7 99.0 349.5
-50.0 334987.4 -20.0 48550.5 10.0 9952.4 40.0 2662.8 70.0 876.2 100.0 339.3
-49.0 312023.0 -19.0 45819.2 11.0 9487.3 41.0 2558.1 71.0 846.9 101.0 329.6
-48.0 290777.1 -18.0 43258.1 12.0 9046.6 42.0 2458.1 72.0 818.7 102.0 320.1
-47.0 271111.3 -17.0 40855.4 13.0 8628.9 43.0 2362.5 73.0 791.6 103.0 311.0
-46.0 252898.7 -16.0 38600.6 14.0 8232.8 44.0 2271.2 74.0 765.5 104.0 302.2
-45.0 236023.7 -15.0 36483.7 15.0 7857.1 45.0 2183.9 75.0 740.4 105.0 293.6
-44.0 220380.2 -14.0 34495.5 16.0 7500.6 46.0 2100.4 76.0 716.2 106.0 285.4
-43.0 205871.3 -13.0 32627.5 17.0 7162.4 47.0 2020.5 77.0 693.0 107.0 277.4
-42.0 192408.1 -12.0 30871.8 18.0 6841.2 48.0 1944.1 78.0 670.6 108.0 269.7
-41.0 179909.1 -11.0 29220.9 19.0 6536.3 49.0 1870.9 79.0 649.1 109.0 262.2
-40.0 168299.9 -10.0 27668.1 20.0 6246.7 50.0 1800.9 80.0 628.3 110.0 255.0
-39.0 157511.9 -9.0 26207.0 21.0 5971.5 51.0 1733.9 81.0 608.4
-38.0 147482.4 -8.0 24831.7 22.0 5710.0 52.0 1669.8 82.0 589.1
-37.0 138153.6 -7.0 23536.6 23.0 5461.3 53.0 1608.3 83.0 570.6
-36.0 129472.6 -6.0 22316.7 24.0 5224.9 54.0 1549.4 84.0 552.7
-35.0 121390.7 -5.0 21167.2 25.0 5000.0 55.0 1493.0 85.0 535.5
-34.0 113863.1 -4.0 20083.6 26.0 4786.0 56.0 1438.9 86.0 518.9
-33.0 106848.7 -3.0 19061.8 27.0 4582.4 57.0 1387.1 87.0 502.9
-32.0 100309.5 -2.0 18098.0 28.0 4388.5 58.0 1337.4 88.0 487.4
-31.0 94210.7 -1.0 17188.5 29.0 4203.9 59.0 1289.7 89.0 472.6
-20 146735.0 1 46709.0 22 17136.0 43 7075.0 64 3227.0 85 1601.0
-19 138447.0 2 44397.0 23 16388.0 44 6801.0 65 3115.0 86 1551.0
-18 130677.0 3 42213.0 24 15676.0 45 6539.0 66 3008.0 87 1503.0
-17 123390.0 4 40150.0 25 15000.0 46 6289.0 67 2905.0 88 1457.0
-16 116554.0 5 38199.0 26 14356.0 47 6049.0 68 2806.0 89 1412.0
-15 110138.0 6 36354.0 27 13744.0 48 5820.0 69 2711.0 90 1369.0
-14 104113.0 7 34608.0 28 13161.0 49 5600.0 70 2620.0 91 1328.0
-13 98454.0 8 32957.0 29 12606.0 50 5391.0 71 2532.0 92 1288.0
-12 93137.0 9 31394.0 30 12078.0 51 5190.0 72 2448.0 93 1250.0
-11 88138.0 10 29914.0 31 11574.0 52 4997.0 73 2367.0 94 1212.0
-10 83438.0 11 28512.0 32 11095.0 53 4813.0 74 2288.0 95 1176.0
-9 79016.0 12 27183.0 33 10637.0 54 4637.0 75 2213.0 96 1142.0
-8 74855.0 13 25925.0 34 10202.0 55 4467.0 76 2141.0 97 1108.0
-7 70938.0 14 24731.0 35 9786.0 56 4305.0 77 2072.0 98 1076.0
-6 67249.0 15 23600.0 36 9389.0 57 4150.0 78 2005.0 99 1045.0
-5 63773.0 16 22526.0 37 9011.0 58 4001.0 79 1940.0 100 1014.0
-4 60498.0 17 21508.0 38 8650.0 59 3858.0 80 1878.0
-3 57410.0 18 20541.0 39 8306.0 60 3721.0 81 1818.0
-2 54498.0 19 19623.0 40 7976.0 61 3590.0 82 1761.0
-1 51750.0 20 18751.0 41 7662.0 62 3464.0 83 1705.0
0 49157.0 21 17923.0 42 7362.0 63 3343.0 84 1652.0
Note: Tolerance for standard thermistors is ±650 Ω,
corresponding to ±1 °C over a 0 °C to 100 °C range.
