Teac AG-D9260 - Parts List (cont.); Component Breakdown; Accessory Components

23
EXPLODED VIEW
REF.NO. PARTSNO. DESCRIPTION
1 9A08904800 PANEL,FRONT[US,C,UK(B)]
9A08904810 PANEL,FRONT[E]
9A08959600 PANEL,FRONT[UK(N)]
2 9A07047400 BADGE[ExceptUK(N)]
9A08887100 BADGE[UK(N)]
3 9A06777500 KNOB,POWER[ExceptUK(N)]
9A08959500 KNOB,STANDBY[UK(N)]
4 9A08904600 KNOB,MODE[ExceptUK(N)]
9A08959300 KNOB,MODE[UK(N)]
5 9A08904700 KNOB,TONE[ExceptUK(N)]
9A08959400 KNOB,TONE[UK(N)]
6 ‑‑‑‑‑‑‑‑‑‑ PHONESPCBASSY
7 9A08886900 BRACKET,PCB
8 9A08905000 FRONTPCBASSY[US,C]
9A08905010 FRONTPCBASSY[E,UK]
9 ‑‑‑‑‑‑‑‑‑‑ JACKPCBASSY
10 ‑‑‑‑‑‑‑‑‑‑ VOLUMEPCBASSY
11 9A08887200 SHEET,LED
12 9A06783600 KNOB,POWER[E,UK(B)]
9A08959100 KNOB,POWER[UK(N)]
13 9A08045300 SHEET,LED(3P)
16 9A07045100 KNOB,FUNCTION[ExceptUK(N)]
9A08958400 KNOB,VOLUME[UK(N)]
17 9A08937100 KNOB,BASS[ExceptUK(N)]
9A08958600 KNOB,ROTARY[UK(N)]
18 9A08904300 WINDOW,FIP
19 9A08886800 BRACKET,TOP
20 9A08888100 CHASSIS,BOTTOM
21 9A08887600 FOOT,FRONT
22 9A06754800 RUBBER,CUSHION
23 9A06755300 FOOT,RUBBER(BLACK)
24 9A08938900 PANEL,REAR[US,C]
9A08938910 PANEL,REAR[E]
9A08938920 PANEL,REAR[UK]
25 9A01375500 PCBHOLDER
26 9A06327100 SUPPORT,CUSHION
27 9A08939400 MAINPCBASSY[US,C]
9A08939410 MAINPCBASSY[E]
9A08939420 MAINPCBASSY[UK]
28 9A08952200 HEATSINK
29 9A08952300 BRACKET,PCB
30 9A08745400 BRACKET,PCB(H/T)
31 ‑‑‑‑‑‑‑‑‑‑ WIREHOLDERPCB
32 9A08939500 INPUTPCBASSY[US,C]
9A08939510 INPUTPCBASSY[E,UK]
33£ 9A08904000 TRANSFORMER,POWER[E,UK(B)]
£ 9A08939300 TRANSFORMER,POWER[US,C]
£ 9A08959700 TRANSFORMER,POWER[UK(N)]
34 9A08887800 BRACKET,TR
35£ 9A07872600 POWERCORD[US,C]
£ 9A07916800 POWERCORD[UK]
£ 9A08956900 POWERCORD[E]
36£ 9A06754900 BUSHING,ACCORD
37 9A08810200 CABINET,TOP[ExceptUK(N)]
9A08885800 CABINET,TOP[UK(N)]
REF.NO. PARTSNO. DESCRIPTION
38 9A08885700 RUBBER
39 9A08904200 KNOB,FUNCTION[ExceptUK(N)]
9A08958500 KNOB,FUNCTION[UK(N)]
40 ‑‑‑‑‑‑‑‑‑‑ SPEAKERJACKPCBASSY
41 9A08957700 BRACKET,POWER[UK]
42 ‑‑‑‑‑‑‑‑‑‑ POWERPUSHPCBASSY
9A08038100 RING,FERRITE
CN10 9A08887300 CABLE,CARD
CN11 9A08887400 CABLE,CARD
F901£ 9A06756100 FUSE,2.5A250V[US,C,E]
F902£ 9A06537400 FUSE,4A250V[E,UK]
F902£ 9A07371000 FUSE,6.3A250V[US,C]
F903,F904£ 9A07044800 FUSE,8A250V
Note
UK(B): Black Version, UK(N): Gold Version
