14
Standard Accessories
Remote Control ............................................................................................................................................................x 1
Instruction Manual.......................................................................................................................................................x 1
RCA audio cable ............................................................................................................................................................x 1
3.5mm - RCA audio cable ..........................................................................................................................................x 1
3.5mm - 3.5mm audio cable ....................................................................................................................................x 1
Subwoofer AC power cord ........................................................................................................................................ x 1
Wall bracket .................................................................................................................................................................... x 2
Design and specications are subject to change without notice.
Wall Mounting
720 mm
Remove the screws from the main unit.
Attach the wall brackets to the main unit with
the screws removed from the main unit
Wall bracket
Drill 2 parallel holes (Ø 3-8 mm each according
to wall type) in the wall. The distance between
the holes should be 720 mm.
Leave a 5 mm gap between the wall and the screw’s head. Lift the unit with the attached wall brackets over
the heads of the screws and slot into place.
Firmly fix 1 dowel into each hole in the wall
if necessary.
Dowel
Solid wall (i.e., Solid brick,
Solid concrete, Solid wood,
Solid wooden battens)
Drywall, Plaster wall,
Lath wall, etc.
5 mm
25-30 mm
To Next Page
