* After setting is complete, the tape length
is indicated for approx. 5 seconds; after
that, the counter indication is resumed.
*Set the tape length again after a cassette
with a different length is loaded or the
power is switched on.
Hate Playback
« Press the POWER switch to ON,
i Press the OPEN/CLOSE ( #) button
and load the required cassette.
. Set the tape length. See above,
. Select the required NR system.
. Press the » button to start playback.
. Adjust the volume with the amplifier’s
control,
7. To end playback, press the STOP but-
ton.
PAPw
Stereo Recording
Recording from a Stereo Syste
1, Press the POWER switch to ON.
2. Press the OPEN/CLOSE ( 4) button
and load the cassette on which the
recording is to be made.
Set the tape length, (See above.)
. Select the NR system used in recording.
|. Press the MPX FILTER button as re-
quired.
6. Set the BIAS/LEVEL controls to their
center click positions,
7, Select the input using the CD DIRECT
select button, (See below.)
Note: Since the audio signal is directly
input to the CD DIRECT IN
terminal, clearer sound can be
recorded.
When the CD DIRECT select
button is set to ON (=), the
signal is input via the CD DIRECT
IN terminal whereas if it is set
to OFF (11), the signals are in-
put via the LINE IN terminals.
8. Play the source to be recorded.
9. Press the RECORD button. The REC
and PAUSE indicators light.
10. Adjust the recording level.
Using the REC LEVEL/BALANCE con-
trals, adjust the recording level of each
channel,
11,Press the » or 1M! button to release
the rec/pause made and start recording.
12.To end recording, press the stop button.
Notes:
© As this deck has an auto tape selector
mechanism, be sure to use cassettes
with tape detection holes. If the cas-
sette does not have a detection hole,
the optimum results will nat be ob-
tained with chrome and metal tapes.
@As C-120 tapes are physically weak
and could become entangled in the
transport mechanism, do not use them.
OPE
CAUTION:
Recording pre-recorded tapes, records,
or other published or broadcast material
may infringe copyright laws. Check
before recording.
Checking CD Level
This is only possible with certain CD
players, including the TEAC CD-P4000.
When the CD CHECK button is pressed,
‘the deck enters the monitor state (SOUR-
CE), allowing you to adjust the recording
level with the CD player in the “fast play-
ae mode.
1, Set the deck to the STOP mode, then
press the CD CHECK button, The linear
counter will indicate “cdch”,
Start the CD player and set to the fast
playback mode.
During fast playback, adjust the re-
cording level using the REC LEVEL
control and BALANCE control.
To release the CD level check, press
the STOP button.
*The checking of CD level is possible when
this deck is in the stop mode.
* Recording level adjustment using CD
level check is only possible when the CD
player is in the fast play mode; do not
perform this adjustment when the CD
player is in the normal play mode.
*Some CD players do not output signals
at the correct level in the fast play mode.
x
e
4,
Adjusting Recording Level
By setting the recording level appropriate-
ly, it is possible to make best use of any
tape’s characteristics,
If the recording level is too low, hiss noise
will be conspicuous in recording. Converse-
ly, if it is too high, the recording will con-
tain distorted sound.
1. Set the AUTO MONITOR button to
SOURCE. In the recording or rec/pause
mode, it is automatically set to SOUR-
CE.
2. So that the peak in the source to be
recorded indicates the specified level
on the PEAK LEVEL METER, adjust
using the REC LEVEL control and
BALANCE control.
|
Turn to adjust the difference in level
between the left and right channels.
—8-
Metal tape
Chrome tape:
Normal tape———
NoRMaL
TTT
32m 012 3
T When the level reaches 19dB
or more, OVER will light.
| A level from 0 to 12 dB i
indicated, |
Press this to clear the peak hold————) 5
Lindication.
MARGIN]
RESET
Record Muting Operation
The ability to leave blank unrecorded
(erased) sections on a tape during recording
is a real advantage in many recording situ-
ations. For instance, you may want to
eliminate undesired portions of an FM
broadcast that you are recording, such as
commercials, station breaks or announce-
ments. You may also want to record a com-
plete program with controlled spacing
between tunes, Such blank sections can
easily be left using the REC MUTE func-
tion.
Automatic Spacing Operation — for a
4-second blank — (during recording)
Press the REC MUTE button during
recording. The tape continues to run, and
a blank of about 4 seconds is left (the
REC indicator flashes),
After 4 seconds, the deck automatically
switches to the record-pause mode (both
the REC and PAUSE indicators light).
To start recording the next tune, press the
> or W button (the PAUSE indicator
goes off).
¢ For a Blank of More Than 4 Seconds
During recording, keep the REC MUTE
button pressed for a longer blank section.
Release the button to enter the record-
pause mode.
For a Blank of Less Than 4 Seconds
After pressing the REC MUTE button
during recording, press the REC MUTE
or PAUSE button before the 4-second
interval has expired, to cancel the muting
mode and engage the record-pause mode,
To restart recording press the « or >
button,
Previously recorded tapes will be erased
automatically when you make a new record-
ing. Alternatively, tapes can be erased by
“recording” on them with the REC LEVEL
control set to “oo”,
